TAILLIGHT ('82-'83 A9/A10)
KE125-A7 KE125 1980 USA CANADA
Taillight ('82-'83 a9/a10) diagram KE125-A7 KE125 1980 USA CANADA
TAILLIGHT ('82-'83 A9/A10) KE125-A7 KE125 1980 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
11009
110091078
ref: 11009
GASKET,TAIL LAMP LENS (NAS)
€ 4.50
23025
230251032
ref: 23025
TAIL LAMP
€ 83.50
23026
230261003
ref: 23026
LENS,TAIL LAMP
€ 50.50
23027
230271020
ref: 23027
BODY-COMP-TAIL LAMP
€ 71.50
23036
230361038
ref: 23036
TAIL LAMP BRACKET
€ 64.50
92001
920011118
ref: 92001
BOLT,HEX HEAD
€ 4.50
92022
92022125
ref: 92022
WASHER,6.5X20X1.6
€ 1.00
92022A
920221561
ref: 92022A
WASHER,8.5X20X1.6
€ 2.50
92022B
92022237
ref: 92022B
WASHER-PLAIN
€ 2.50
92027
92027162
ref: 92027
COLLAR-REAR FENDER
€ 4.50
92069
92069074
ref: 92069
BULB,6V-32X3CP
€ 4.50
92075
920751094
ref: 92075
DAMPER,TAIL LAMP
€ 10.00
92075A
920751095
ref: 92075A
DAMPER
€ 2.00
92075B
920751305
ref: 92075B
REAR FENDER DAMPER
€ 3.00
92075C
92075209
ref: 92075C
DAMPER RUBBER
€ 3.00
92075D
92075310
ref: 92075D
DAMPER,RUBBER
€ 2.50
110
112G0625
ref: 110
BOLT-UPSET,6X25
€ 4.00
220
220R0440
ref: 220
SCREW-PAN-CROS,4X40
€ 3.00
311
311B0600
ref: 311
NUT,6MM
€ 0.50
411
411B0600
ref: 411
WASHER-PLAIN,6MM
€ 0.50
461
461F0600
ref: 461
WASHER-SPRING,6MM
€ 0.50
