OWNER TOOLS G4TR-C ('70-'73)

G4TR TRAILBOSS 1970 USA CANADA / MPH

Owner tools g4tr-c ('70-'73) diagram G4TR TRAILBOSS 1970 USA CANADA / MPH

prices are in EUR

ref

part #

description

quantity

56008008
ref: 1

BAG,TOOL

€ 16.50

960B1014
ref: 2

WRENCH-OPEN END,10X14

€ 4.00

960B1317
ref: 3

WRENCH,OPEN END,13X17

€ 0.00

92106002
ref: 4

GRIP-SCRE DRIVER

€ 7.00

921071052
ref: 5

TOOL-DRIVER

€ 6.50

92107005
ref: 6

SCREW DRIVER-#3 PHLIP

€ 7.00

92110006
ref: 7

WRENCH,BOX,17X21

€ 13.00

92109004
ref: 8

WRENCH,BOX,19X22

€ 18.50

56007027
ref: 9

TOOL KIT

€ 0.00

56019033
ref: 10

PULLER-MAGNETO

€ 22.50

92104002
ref: 11

LIQUID GASKET

€ 69.50
