CYLINDER HEAD/CYLINDER ('74-'75)

G4TR TRAILBOSS 1970 USA CANADA / MPH

Cylinder head/cylinder ('74-'75) diagram G4TR TRAILBOSS 1970 USA CANADA / MPH

CYLINDER HEAD/CYLINDER ('74-'75) G4TR TRAILBOSS 1970 USA CANADA / MPH

CYLINDER HEAD/CYLINDER ('74-'75) G4TR TRAILBOSS 1970 USA CANADA / MPH

prices are in EUR

ref

part #

description

quantity

1

311B0800
ref: 1

NUT,8MM

€ 0.50

2

461F0800
ref: 2

WASHER-SPRING,8MM

€ 0.50

3

410B0800
ref: 3

WASHER-PLAIN-SMALL,8M

€ 0.50

4

1100109021
ref: 4

CYLINDER HEAD,FLAT BLACK

€ 359.50

5

92075109
ref: 5

DAMPER,CYLINDER HEAD/

€ 2.00

6

11004033
ref: 6

GASKET-HEAD,CYLINDER (NAS)

€ 9.00

7

B7HSA
ref: 7

NGK SPARK-PLUG B7HS

€ 3.00

8

1100511521
ref: 8

CYLINDER,FLAT BLACK

€ 336.00

8

110051141
ref: 8

ENGINE CYLINDER

€ 300.50

9

110601200
ref: 9

GASKET,CYLINDER BASE (NAS)

€ 5.50

10

92075213
ref: 10

CYLINDER DAMPER,RUBBER

€ 8.00

11

92004051
ref: 11

STUD,L=30.5

€ 5.50

12

92019008
ref: 12

NUT-LOCK,6MM

€ 3.00

13

110091992
ref: 13

GASKET,EXHAUST PIPE (NAS)

€ 5.50

14

18070009
ref: 14

COLLAR,EXHAUST PIPE H

€ 7.00

15

1806905221
ref: 15

EXHAUST PIPE HOLDER,FLAT BLACK

€ 36.50
