HEADLIGHT ('78 D1)
KZ1000D1 Z1R 1978 CANADA
Headlight ('78 d1) diagram KZ1000D1 Z1R 1978 CANADA
HEADLIGHT ('78 D1) KZ1000D1 Z1R 1978 CANADA
×
prices are in EUR
ref
part #
description
quantity
1
920091033
ref: 1
SCREW,FOCUS ADJUSTING
€ 3.50
2
23014005
ref: 2
SPRING-FOCUS ADJUST
€ 2.50
3
23021004
ref: 3
WASHER,4.1X8X0.8
€ 2.00
4
23020018
ref: 4
NUT,4MM,FOCUS ADJUST
€ 3.00
5
230061003
ref: 5
RIM,HEAD LAMP
€ 57.00
6
23019023
ref: 6
SCREW-PAN HEAD,5X12
€ 3.50
7
23021012
ref: 7
WASHER
€ 3.00
8
23020023
ref: 8
NUT,5MM
€ 3.00
9
220B0312
ref: 9
SCREW-PAN CROS,3X12
€ 2.00
10
23072001
ref: 10
RETAINER,HEAD LAMP
€ 26.00
11
230071009
ref: 11
LENS UNIT, HEAD LAMP
€ 127.00
12
920691002
ref: 12
PHILIPS (H4 12342
BULB,12V-60155W
€ 15.00
13
490161016
ref: 13
COVER-SEAL
€ 16.00
14
23074001
ref: 14
HOLDER,HEAD LAMP
€ 28.00
15
315B1000
ref: 15
NUT,10MM
€ 0.50
16
461F1000
ref: 16
WASHER-SPRING,10MM
€ 0.50
17
411B1000
ref: 17
WASHER-PLAIN,10MM
€ 0.50
18
23066022
ref: 18
DAMPER
€ 6.00
19
23066021
ref: 19
DAMPER
€ 6.00
20
23052011
ref: 20
COLLAR,HEAD LAMP
€ 8.50
21
113G1045
ref: 21
BOLT-SMALL-FINE,10X45
€ 2.50
22
110R0635
ref: 22
BOLT 6X35
€ 3.50
23
461F0600
ref: 23
WASHER-SPRING,6MM
€ 0.50
24
411B0600
ref: 24
WASHER-PLAIN,6MM
€ 0.50
25
920751004
ref: 25
DAMPER,TAIL LAMP
€ 2.50
26
92075310
ref: 26
DAMPER,RUBBER
€ 2.50
27
920151024
ref: 27
NUT,HEAD LAMP FITTING
€ 4.00
