ENGINE COVER

ref

part #

description

quantity

11009

110091164
ref: 11009

GASKET,BRKR POINT CAP (MCA)

€ 4.50

11009A

110091165
ref: 11009A

GASKET,GENERATOR COV (MCA)

€ 7.50

11009B

110091285
ref: 11009B

GASKET,MISSION COVER (MCA)

€ 8.50

11009C

14046035
ref: 11009C

GASKET, R.H.ENG COVER (MCA)

€ 20.00

11012

110121377
ref: 11012

CAP,PULSING COIL

€ 35.50

12053

120531006
ref: 12053

GUIDE-CHAIN

€ 6.50

14025

140251249
ref: 14025

COVER,CLUTCH ADJUSTIN

€ 24.00

14025A

140251486
ref: 14025A

COVER,TRANSMISSION

€ 62.00

14026

140261081
ref: 14026

COVER-CHAIN

€ 99.50

14031

140311167
ref: 14031

COVER-GENERATOR

€ 127.00

14032

140321091
ref: 14032

COVER-CLUTCH

€ 64.50

16115

16115013
ref: 16115

PLUG-OIL FILLER

€ 13.50

52005

520051009
ref: 52005

GAUGE,OIL LEVEL

€ 12.00

92001

92001164
ref: 92001

BOLT,6X35

€ 3.50

92004

920041044
ref: 92004

STUD,10MM,CHANGE PEDA

€ 11.50

92022

92022077
ref: 92022

WASHER,6.1X12X1

€ 0.50

92037

21126008
ref: 92037

CLAMP,WIRING HARNESS

€ 3.00

92049

920491003
ref: 92049

OIL SEAL,CLUTCH

€ 8.00

92049A

920491017
ref: 92049A

SEAL-OIL,SD-8187

€ 6.50

92049B

92050024
ref: 92049B

OIL SEAL SC325210

€ 5.00

92049C

92051005A
ref: 92049C

OIL SEAL,TB13225.5

€ 5.50

92055

92055049
ref: 92055

'0'RING,31MM

€ 2.50

112

112B0614
ref: 112

BOLT-UPSET 6X14

€ 2.50

120

120Z0614
ref: 120

BOLT-SOCKET,6X14

€ 2.50

120A

120Z0630
ref: 120A

BOLT-SOCKET,6X30

€ 3.00

120B

120Z0640
ref: 120B

BOLT-SOCKET

€ 3.00

120C

120Z0670
ref: 120C

BOLT-SOCKET,6X70

€ 3.00

120D

120Z0680
ref: 120D

BOLT-SOCKET,6X80

€ 2.50

220

220B0620
ref: 220

SCREW-PAN HEAD,6X20

€ 2.50

220A

220E0630
ref: 220A

SCREW-PAN HEAD,6X30

€ 2.00
