HEADLIGHT ('80-'81 A7/A8)

KE125-A10 KE125 1983 USA USA CANADA

Headlight ('80-'81 a7/a8) diagram KE125-A10 KE125 1983 USA USA CANADA

HEADLIGHT ('80-'81 A7/A8) KE125-A10 KE125 1983 USA USA CANADA

HEADLIGHT ('80-'81 A7/A8) KE125-A10 KE125 1983 USA USA CANADA

prices are in EUR

ref

part #

description

quantity

1

230041030
ref: 1

LAMP-HEAD

€ 221.50

2

23013007
ref: 2

SCREW ASY,LENS UNIT

€ 3.50

3

230061004
ref: 3

RIM-LAMP

€ 56.00

4

230135001
ref: 4

SCREW ASSY,FOCUS AJST

€ 10.50

5

220B0512
ref: 5

SCREW-PAN-CROS

€ 0.50

6

23072002
ref: 6

RETAINER,SEALED BEAM

€ 29.50

7

23009015
ref: 7

SPRING,HEAD LAMP LENS

€ 3.50

8

23007055
ref: 8

LENS-COMP,4020 MARK

€ 60.00

9

23008044
ref: 9

SOCKET-ASSY,HEAD LAMP

€ 15.00

10

23081001
ref: 10

COVER,HD LAMP SOCKET

€ 6.50

11

92075209
ref: 11

DAMPER RUBBER

€ 3.00

12

2300510076Z
ref: 12

BODY-COMP-HEAD LAMP,B

€ 71.50

13

23021010
ref: 13

WASHER

€ 2.50

14

317B0800
ref: 14

NUT,8M/M

€ 0.50

15

411B0800
ref: 15

WASHER-PLAIN,8MM

€ 0.50

16

411D0800
ref: 16

WASHER,PLAIN,8MM

€ 2.00

17

461F0800
ref: 17

WASHER-SPRING,8MM

€ 0.50

18

920271105
ref: 18

COLLAR,L=15.6

€ 4.50

19

920751077
ref: 19

DAMPER,HEAD LAMP

€ 3.00

20

920751078
ref: 20

DAMPER,HEAD LAMP

€ 3.00

21

110341701
ref: 21

HEADLAMP BODY BRACKET

€ 52.50

22

112G0625
ref: 22

BOLT-UPSET,6X25

€ 4.00

23

461F0600
ref: 23

WASHER-SPRING,6MM

€ 0.50

24

92022125
ref: 24

WASHER,6.5X20X1.6

€ 1.00

25

92027241
ref: 25

COLLAR

€ 4.50

26

114N0832
ref: 26

BOLT-SMALL,8X32

€ 3.00

27

220B0512
ref: 27

SCREW-PAN-CROS

€ 0.50

28

461F0500
ref: 28

WASHER-SPRING,5MM

€ 0.50
