CARBURETOR

ref

part #

description

quantity

1

130G0620
ref: 1

BOLT,FLANGED,6X20

€ 2.50

2

160651029
ref: 2

HOLDER-CARBURETOR

€ 63.00

3

92036018
ref: 3

CIRCLIP

€ 2.50

4

92037116
ref: 4

CLAMP

€ 10.50

5

220B0535
ref: 5

SCREW-PAN-CROS

€ 2.00

6

160011337
ref: 6
VM36SS

CARBURETOR ASSY

€ 269.50

7

160021006
ref: 7

ADJUSTER-CABLE

€ 6.50

8

16003004
ref: 8

NUT-CABLE ADJUST LOCK

€ 4.50

9

130701014
ref: 9

GUIDE,CABLE

€ 24.50

10

110091191
ref: 10

GASKET,CABLE GUIDE (NAS)

€ 4.50

11

160041010
ref: 11

TOP,MIXING CHAMBER

€ 26.50

12

16008011
ref: 12

CLAMP,CABLE GUIDE

€ 4.50

13

16006028
ref: 13

SPRING,THROTTLE VALVE

€ 8.50

14

920091037
ref: 14

SCREW,4X5

€ 2.50

15

160071007
ref: 15

SEAT-SPRING,THROTTLE

€ 6.50

16

16008010
ref: 16

CLAMP,E-TYPE

€ 5.00

17

160091082
ref: 17

JET NEEDLE,J8-6E02

€ 18.50

18

160251057
ref: 18

THROTTLE VALVE,C.A3.0

€ 76.00

19

160211034
ref: 19

SCREW-THROTTLE STOP

€ 12.50

20

920811200
ref: 20

SPRING,THROTT STP SCR

€ 5.50

21

16014006
ref: 21

SCREW-PILOT AIR

€ 9.00

22

16022007
ref: 22

SPRING-THR STOP SCREW

€ 5.50

23

110091076
ref: 23

GASKET,FLOAT VALVE (NAS)

€ 2.00

24

16038019
ref: 24

PLATE,FLOAT CHAMBER

€ 12.00

25

16030020
ref: 25

VALVE-FLOAT

€ 42.00

26

92064031
ref: 26

PILOT JET, # 60 A

€ 9.00

27

160171088
ref: 27

NEEDLE JET,R-4

€ 23.50

28

160651045
ref: 28

HOLDER-CARBURETOR,NEE

€ 40.50

29

920631019
ref: 29

JET-MAIN,#162.5R

€ 11.50

29

920631027
ref: 29

MAIN JET,#172.5R

€ 8.00

29

920631022
ref: 29

JET-MAIN,#170R

€ 11.50

29

920631020
ref: 29

MAIN JET,#165R

€ 7.50

29

920631021
ref: 29

MAIN JET,#167.5R

€ 7.00

30

16032008
ref: 30

PIN,FLOAT

€ 4.00

31

16055009
ref: 31

ARM-FLOAT

€ 12.50

32

16031029
ref: 32

FLOAT

€ 40.00

33

16019028
ref: 33

GASKET,FLOAT CHAMBER (NAS)

€ 11.50

34

214B0516A
ref: 34

UNAVAILABLE IN PRICE BOOK

€ 0.50

35

461F0500
ref: 35

WASHER-SPRING,5MM

€ 0.50

36

16038009
ref: 36

GASKET,MAIN JET COVER

€ 5.50

37

16049006
ref: 37

COVER-MAIN JET

€ 10.50

38

920591185
ref: 38

HOSE,AIR VENT

€ 2.50

39

16039015
ref: 39

CAP,STARTER PLUNGER

€ 4.50

40

16012019
ref: 40

CAP-STARTER PLUNGER

€ 12.50

41

131691052
ref: 41

SPRING PLATE STARTER

€ 8.50

42

131681048
ref: 42

LEVER STARTER PLUNGER

€ 15.00

43

670B1509
ref: 43

O RING,9MM

€ 1.00

44

920811181
ref: 44

SPRING,STARTER PLUNG

€ 3.00

45

160161008
ref: 45

PLUNGER,ASSY STARTER

€ 17.00

46

920371184
ref: 46

CLAMP,HOSE

€ 1.00

47

920591123
ref: 47

TUBE,7.5X12.5X225

€ 17.00
