IGNITION SWITCH

ref

part #

description

quantity

11045

110451354
ref: 11045
AR

BRACKET,REFLECTOR,FR

€ 5.50

11045A

110451355
ref: 11045A
AR

BRACKET,REFLECTOR,FR

€ 6.00

11045B

110451621
ref: 11045B
AR

BRACKET,REFLECTOR,RR

€ 14.00

11045C

110451641
ref: 11045C

BRACKET,REAR BRAKE SW

€ 5.50

14024

140241532
ref: 14024

COVER,SIDE STAND SWIT

€ 5.00

21007B

210075037
ref: 21007B

ROTOR,LOCK,TANK CAP

€ 65.50

27004B

270045484
ref: 27004B

SWITCH-ASSY

€ 395.00

27005B

270055102
ref: 27005B

SWITCH-ASSY-IGNITION

€ 249.50

27008A

270081173
ref: 27008A

KEY-LOCK,BLANK

€ 13.00

27010

270101152
ref: 27010

SWITCH,BRAKE LAMP

€ 20.00

27010A

270101223
ref: 27010A

SWITCH,SIDE STAND

€ 48.00

27011

27011004
ref: 27011

SPRING-BRAKE LAMP SW

€ 2.50

27016B

270165218
ref: 27016B

LOCK-ASSY,SEAT

€ 59.50

28012

280121003
ref: 28012
AR

REFLECTOR,REFLEX

€ 15.00

28012A

280121077
ref: 28012A

REFLECTOR-REFLEX

€ 16.00

59071

590711103
ref: 59071

JOINT

€ 5.50

130

130B0510
ref: 130

BOLT-FLANGED

€ 1.50

130A

130D0610
ref: 130A

BOLT-FLANGED

€ 0.50

311

311B0500
ref: 311
AR

NUT-HEX

€ 0.50

461

461F0500
ref: 461
AR

WASHER-SPRING,5MM

€ 0.50

461A

461L0600
ref: 461A

WASHER-SPRING

€ 0.50

92002

920021132
ref: 92002
AR

BOLT,6X12

€ 2.50

92002A

920021333
ref: 92002A

BOLT

€ 1.50

92009

920091459
ref: 92009

SCREW

€ 2.50

92015

920151237
ref: 92015
AR

NUT,FLANGED,6MM,BLACK

€ 3.50

92015A

920151259
ref: 92015A
AR

NUT,FLANGED,5MM

€ 2.50

92015A

920151259
ref: 92015A
EUGRITNL

NUT,FLANGED,5MM

€ 2.50

92015B

920151367
ref: 92015B
AR

NUT,FLANGED,6MM

€ 0.50
