FOOTRESTS/STANDS/BRAKE PEDAL ('6

G3TR BUSHMASTER 1969 USA CANADA

Footrests/stands/brake pedal ('6 diagram G3TR BUSHMASTER 1969 USA CANADA

FOOTRESTS/STANDS/BRAKE PEDAL ('6 G3TR BUSHMASTER 1969 USA CANADA

FOOTRESTS/STANDS/BRAKE PEDAL ('6 G3TR BUSHMASTER 1969 USA CANADA

prices are in EUR

ref

part #

description

quantity

1

34002048
ref: 1

FOOTREST BAR

€ 123.00

2

92076006
ref: 2

DAMPER,STEP

€ 10.00

3

92022049
ref: 3

WASHER-FOLDING PEG

€ 2.00

4

34006002
ref: 4

SPRING-FOOTREST PEG

€ 3.00

5

340111045
ref: 5

STAND-CENTER

€ 50.00

6

34019006
ref: 6

SHAFT-MAIN STAND

€ 9.00

7

34023005
ref: 7

SPRING-MAIN STAND

€ 6.50

8

92022085
ref: 8

WASHER,15.3X24X1.2

€ 2.50

9

34024053
ref: 9

STAND,SIDE

€ 23.00

10

34025001
ref: 10

SPRING,SIDE STAND

€ 9.50

11

43001024
ref: 11

PEDAL-BRAKE

€ 11.00

11

43001014
ref: 11

PEDAL-BRAKE

€ 19.50

12

43005005
ref: 12

SPRING-BRAKE PEDAL

€ 3.00

?

430105003
ref: ?
Includes items 13 -

BRAKE ROD ASSY

€ 15.00

14

43012001
ref: 14

SPRING,BRAKE ROD

€ 3.00

15

92015042
ref: 15

NUT-BRAKE ROD ADJUST

€ 4.00

16

92043039
ref: 16

PIN,BRAKE ROD

€ 4.50

17

113G1025
ref: 17

BOLT-SMALL-FINE,10X25

€ 2.50

18

116B0816
ref: 18

BOLT-HEX HEAD,8X16

€ 0.50

19

115G0820
ref: 19

BOLT,8X20

€ 2.00

20

315B1000
ref: 20

NUT,10MM

€ 0.50

21

410B0600
ref: 21

WASHER-PLAIN-SMALL,6M

€ 0.50

22

461F0800
ref: 22

WASHER-SPRING,8MM

€ 0.50

23

480J1600
ref: 23

CIRCLIP-TYPE-C,16MM

€ 2.50

24

550D2015
ref: 24

PIN-COTTER,2.0X15

€ 1.00

25

550D3030
ref: 25

PIN-COTTER,3.0X30

€ 1.50
