Genuine ZX Kawasaki Parts delivered quickly!


SIDE COVER/CHAIN CASE(ZX400-L3)

ZX400L3 ZXR400 1993 EUROPE UK FR AR FG IT

Side cover/chain case(zx400-l3) diagram ZX400L3 ZXR400 1993 EUROPE UK FR AR FG IT

SIDE COVER/CHAIN CASE(ZX400-L3) ZX400L3 ZXR400 1993 EUROPE UK FR AR FG IT
SIDE COVER/CHAIN CASE(ZX400-L3) ZX400L3 ZXR400 1993 EUROPE UK FR AR FG IT
SIDE COVER/CHAIN CASE(ZX400-L3) ZX400L3 ZXR400 1993 EUROPE UK FR AR FG IT
prices are in EUR
ref
part #
description
quantity
36014
360141167
ref: 36014
CASE-CHAIN
360141167
€ 65.50
36030H
360305165KE
ref: 36030H
EUFRITUK
COVER-SIDE,LH,GREEN/W
€ 394.50
36030I
360305166KE
ref: 36030I
EUFRITUK
COVER-SIDE,RH,GREEN/W
€ 394.50
36030J
360305167KE
ref: 36030J
FG
COVER-SIDE,LH,GREEN/W
€ 394.50
36030K
360305168KE
ref: 36030K
FG
COVER-SIDE,RH,GREEN/W
€ 394.50
36030L
360305169H8
ref: 36030L
AREUFRITUK
COVER-SIDE,LH,EBONY
€ 394.50
132
132E0612
ref: 132
BOLT-FLANGED-SMALL
132E0612
€ 3.50
36030M
360305170H8
ref: 36030M
AREUFRITUK
COVER-SIDE,RH,EBONY
€ 394.50
36030N
360305171H8
ref: 36030N
FG
COVER-SIDE,LH,EBONY
€ 394.50
36030O
360305172H8
ref: 36030O
FG
COVER-SIDE,RH,EBONY
€ 394.50
39156
391561241
ref: 39156
PAD,SIDE COVER,LH
€ 14.00
92009
920091287
ref: 92009
SCREW,6X14
920091287
€ 1.50
92009A
920091354
ref: 92009A
SCREW,6X30
920091354
€ 4.00
92009B
920091654
ref: 92009B
SCREW
920091654
€ 0.50
92015
920151569
ref: 92015
NUT,5MM
920151569
€ 4.50
92022
920221038
ref: 92022
WASHER,PLAIN
920221038
€ 2.50
92022A
920221654
ref: 92022A
WASHER,6.5X16X1.0
920221654
€ 2.50
92071
920711027
ref: 92071
FG
GROMMET,AIR CLEANER
920711027
€ 3.00
92071A
920711043
ref: 92071A
GROMMET,SIDE COVER
920711043
€ 3.50
