GEAR CHANGE MECHANISM

ref

part #

description

quantity

1

220B0616
ref: 1

SCREW-PAN HEAD,6X16

€ 2.50

2

131511001
ref: 2

SWITCH-COMP,NEUTRAL

€ 9.50

2

131511001
ref: 2
KE175-B3

SWITCH-COMP,NEUTRAL

€ 9.50

3

13146002
ref: 3

GASKET,NEUTRAL SWITCH (NAS)

€ 2.50

4

410B0600
ref: 4

WASHER-PLAIN-SMALL,6M

€ 0.50

5

210071003
ref: 5

ROTOR,TOP & NEUTRAL

€ 4.50

5

210071003
ref: 5
KE175-B3

ROTOR,TOP & NEUTRAL

€ 4.50

6

13239002
ref: 6

DRUM ASSY-GEAR CHANGE

€ 125.00

7

92042014
ref: 7

PIN-GEAR CHANGE DRUM

€ 0.50

8

13142009
ref: 8

PLATE-CHANGE DRUM PIN

€ 6.00

9

464H0600
ref: 9

WASHER-LOCK,6MM

€ 0.50

10

220B0614
ref: 10

SCREW-PAN HEAD,6X14

€ 2.00

11

550D3020
ref: 11

PIN-COTTER,3.0X20

€ 2.00

12

92043005
ref: 12

PIN,DOWEL,8X15

€ 4.50

13

13140030
ref: 13

FORK-SELECTOR

€ 60.50

14

13140049
ref: 14

FORK-SELECTOR

€ 38.00

15

13140050
ref: 15

FORK-SELECTOR

€ 38.00

16

13156064
ref: 16

PEDAL,GEAR CHANGE

€ 87.00

17

13157004
ref: 17

RUBBER-CHANGE PEDAL

€ 4.00

18

112G0620
ref: 18

BOLT 6X20

€ 1.00

19

13161019
ref: 19

LEVER ASSY-GEAR CHNG

€ 50.00

20

920811129
ref: 20

SPRING,TENTION

€ 6.50

20

920811129
ref: 20
KE175-B2/-B3

SPRING,TENTION

€ 6.50

21

92027121
ref: 21

COLLAR

€ 5.50

22

921441720
ref: 22

SPRING,CHANGE LEVER

€ 3.00

23

312B0800
ref: 23

NUT,8MM

€ 0.50

24

920011401
ref: 24

BOLT,RETURN SPRING

€ 3.00

25

13169002
ref: 25

PLATE,CHANGE DRUM POS

€ 3.00

26

220B0614
ref: 26

SCREW-PAN HEAD,6X14

€ 2.00

27

92081091
ref: 27

SPRING-COIL

€ 3.50

28

13168017
ref: 28

LEVER-CHANGE DRUM,B

€ 4.00

29

13168021
ref: 29

LEVER-GEAR CHNG DRUM

€ 2.00

30

92011023
ref: 30

SCREW-PAN HEAD

€ 2.50

all assemblies
