CHASSIS ELECTRICAL EQUIPMENT ('8
KZ550A4 1983 USA CANADA
Chassis electrical equipment ('8 diagram KZ550A4 1983 USA CANADA
CHASSIS ELECTRICAL EQUIPMENT ('8 KZ550A4 1983 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
26001
260011202
ref: 26001
HARNESS,SUB
€ 51.00
26001A
260011289
ref: 26001A
HARNESS,MAIN
€ 154.50
26001B
260011411
ref: 26001B
HARNESS,SUB
€ 27.00
26001C
260011460
ref: 26001C
HARNESS,MAIN
€ 121.50
26004
260041002
ref: 26004
FUSE-ASSY
€ 55.00
26004A
260041014
ref: 26004A
FUSE-ASSY,ACCESSORY
€ 47.00
26006
26006003
ref: 26006
FUSE 10A
€ 3.00
26006A
26006005
ref: 26006A
FUSE 20A
€ 3.50
26006B
260061002
ref: 26006B
FUSE,10A,L=30M/M
€ 3.00
26011
26011095
ref: 26011
WIRE-LEAD,L=285
€ 8.00
26011A
260111032
ref: 26011A
WIRE-LEAD,BATTERY GRO
€ 17.00
26011B
260111155
ref: 26011B
WIRE-LEAD,BATTERY GRO
€ 26.00
26012
260121004
ref: 26012
US
BATTERY 12V 12AH
€ 97.00
26012A
260121044
ref: 26012A
CN
BATTERY
€ 97.00
27002
27002011
ref: 27002
RELAY-ASSY,TURN SIGNA
€ 69.50
27002A
27002016
ref: 27002A
RELAY-ASSY,HAZARD
€ 26.50
27003
270031014
ref: 27003
HORN
€ 91.00
27010
270101024
ref: 27010
SWITCH,RESERV LIGHTIN
€ 149.00
27010A
28019001
ref: 27010A
SWITCH,OUTAGE INDICTR
€ 46.00
92001
92001137
ref: 92001
BOLT,HEX HEAD,6M/M
€ 4.00
92037
92037086
ref: 92037
CLAMP-WIRE HARNESS
€ 4.00
92037A
920371069
ref: 92037A
CLAMP,L=60
€ 1.50
92037A
920371069
ref: 92037A
CLAMP,L=60
€ 1.50
92037B
920371324
ref: 92037B
CLAMP,L=80
€ 3.00
92072
92072030
ref: 92072
BAND,SHORT
€ 3.00
92072A
92072031
ref: 92072A
BAND,MIDDLE
€ 3.00
92072B
92072032
ref: 92072B
BAND,LONG
€ 3.00
92075
92075279
ref: 92075
DAMPER,FUSE
€ 3.50
110
110B0514A
ref: 110
BOLT,HEX HEAD,5X14
€ 0.50
114
115G0816
ref: 114
BOLT-HEX,HEAD 8X16
€ 0.50
220
220B0620
ref: 220
SCREW-PAN HEAD,6X20
€ 2.50
410
410B0600
ref: 410
WASHER-PLAIN-SMALL,6M
€ 0.50
411
411B0500
ref: 411
WASHER-PLAIN,5MM
€ 0.50
461
461F0500
ref: 461
WASHER-SPRING,5MM
€ 0.50
461A
461F0600
ref: 461A
WASHER-SPRING,6MM
€ 0.50
461B
461F0800
ref: 461B
WASHER-SPRING,8MM
€ 0.50
