KICKSTARTER MECHANISM

ref

part #

description

quantity

1

920011577
ref: 1

BOLT,FLANGED,8X35

€ 2.50

2

130641002
ref: 2

PEDAL ASSY,KICK

€ 181.50

3

130611001
ref: 3

BOSS,KICK PEDAL

€ 28.50

4

13063004
ref: 4

DAMPER,KICK PEDAL

€ 6.50

5

482K9000
ref: 5

CIRCLIP-TYPE-E,9MM

€ 2.50

6

600A0800
ref: 6

BALL-STEEL,1/4

€ 0.50

7

92081020
ref: 7

SPRING-KICK PEDAL

€ 2.50

8

130661001
ref: 8

SHAFT,KICK

€ 51.00

9

13078011
ref: 9

RATCHET

€ 58.50

10

480J1900
ref: 10

CIRCLIP-TYPE-C,19MM

€ 1.00

11

480J2000
ref: 11

CIRCLIP-TYPE-C,20MM

€ 1.00

12

590511007
ref: 12

GEAR,KICK,20T

€ 28.50

13

92022112
ref: 13

WASHER,20.5X30X1,STEE

€ 6.00

14

92081104
ref: 14

SPRING-RATCHET

€ 6.50

15

92102008
ref: 15

CAP-KICKSTARTER

€ 4.00

16

13070009
ref: 16

GUIDE,KICK SPRING

€ 8.00

17

13169007
ref: 17

PLATE-DRUM LEV POSTON

€ 9.00

18

221B0612
ref: 18

SCREW-CNTSNK HD,6X12

€ 1.50

19

480J2000
ref: 19

CIRCLIP-TYPE-C,20MM

€ 1.00

20

92028175
ref: 20

BUSHING,KICK SHAFT

€ 12.50

21

92082006
ref: 21

SPRING,KICK RETURN

€ 17.00

22

112G0614
ref: 22

BOLT-UPSET,6X14

€ 2.50

23

13072012
ref: 23

STOPPER,KICKSTARTER

€ 7.00
