HANDLEBAR ('73-'75 D/E/F & '76 A
KH500A8 1976 CANADA
Handlebar ('73-'75 d/e/f & '76 a diagram KH500A8 1976 CANADA
HANDLEBAR ('73-'75 D/E/F & '76 A KH500A8 1976 CANADA
×
prices are in EUR
ref
part #
description
quantity
1
46003017
ref: 1
HANDLEBAR
€ 38.00
2
920011405
ref: 2
BOLT,8X38
€ 10.00
3
461F0800
ref: 3
WASHER-SPRING,8MM
€ 0.50
4
46012008
ref: 4
HOLDER-HANDLE,UPP
€ 23.00
5
46012010
ref: 5
HOLDER-HANDLE,LWR
€ 20.00
6
92075275
ref: 6
DAMPER,HANDLE
€ 6.00
7
92022196
ref: 7
WASHER,10.5X30X2
€ 2.00
8
461F1000
ref: 8
WASHER-SPRING,10MM
€ 0.50
9
314B1000
ref: 9
NUT,10MM
€ 0.50
10
554A0800
ref: 10
PIN-SNAP,8MM
€ 1.00
11
56003009
ref: 11
H1-D/E/F
MIRROR-ASSY,LH
€ 50.00
11
56003019
ref: 11
KH500-A8
MIRROR-ASSY,LH
€ 51.00
12
56002020
ref: 12
H1-D/E/F
MIRROR-ASSY,RH
€ 47.50
12
56002029
ref: 12
KH500-A8
MIRROR-ASSY,RH
€ 49.00
13
46019023
ref: 13
H1-D/E/F
GRIP ASSY-THROTTLE
€ 13.50
13
46019041
ref: 13
KH500-A8
GRIP-ASSY,THROTTLE
€ 28.00
14
46132003
ref: 14
H1-D/E
CASE ASSY,R.H
€ 96.50
14
46132019
ref: 14
H1-F
CASE ASSEMBLY,RH
€ 0.00
14
46132027
ref: 14
KH500-A8
CASE ASSEMBLY,RH
€ 256.00
14
46132028
ref: 14
KH500-A8 CANADA
CASE ASSEMBLY,RH
€ 179.50
15
46043006
ref: 15
KNOB-ASSY,LIGHTING SW
€ 8.00
16
220B0535
ref: 16
SCREW-PAN-CROS
€ 2.00
17
220B0522
ref: 17
SCREW-PAN-CROS
€ 0.50
18
46075017
ref: 18
H1-D/E/F
GRIP,LH
€ 15.50
18
46075028
ref: 18
KH500-A8
GRIP,LH
€ 32.00
19
46091014
ref: 19
H1-D
CASE ASSEMBLY,LH
€ 308.50
19
46091047
ref: 19
H1-E/F,KH500-A8
CASE ASSEMBLY,LH
€ 280.50
20
46043005
ref: 20
KNOB-LIGHTING SW L.H
€ 6.50
21
46044013
ref: 21
KNOB,LIGHTING SWITCH,
€ 8.00
22
270101009
ref: 22
H1-D/E
SWITCH ASSY,HORN BUTN
€ 5.50
22-1
270101001
ref: 22-1
H1-F,KH500-A8
BUTTON, HORN PUSH
€ 6.50
23
270101009
ref: 23
H1-D/E
SWITCH ASSY,HORN BUTN
€ 5.50
24
270101009
ref: 24
H1-D/E
SWITCH ASSY,HORN BUTN
€ 5.50
24-1
270101009
ref: 24-1
H1-D/E
SWITCH ASSY,HORN BUTN
€ 5.50
25
220B0530
ref: 25
SCREW-PAN-CROS
€ 2.00
26
46096009
ref: 26
LEVER,STARTER
€ 15.50
27
92095012
ref: 27
WASHER-LOCK
€ 3.50
28
410B0600
ref: 28
WASHER-PLAIN-SMALL,6M
€ 0.50
29
110B0608
ref: 29
BOLT-HEX HEAD,6X8
€ 0.50
30
46076026
ref: 30
H1-D
LEVER ASSY-CLUTCH
€ 35.00
30
46076036
ref: 30
H1-E/F
LEVER ASSY,CLUTCH
€ 47.00
30
46076051
ref: 30
KH500-A8
LEVER ASSY,CLUTCH
€ 27.00
31
46092015
ref: 31
H1-D
LEVER-GRIP,CLUTCH
€ 11.50
31
46092015
ref: 31
H1-E/F
LEVER-GRIP,CLUTCH
€ 11.50
31
46092023
ref: 31
KH500-A8
LEVER-GRIP,CLUTCH
€ 17.00
32
92007020
ref: 32
H1-D
BOLT-HEX HEAD,5X20
€ 2.50
32-1
92007046
ref: 32-1
H1-E/F
BOLT,HEX HEAD,5X22
€ 4.50
32-1
92007047
ref: 32-1
KH500-A8
BOLT,HEX HEAD
€ 6.50
33
46059011
ref: 33
H1-D, USE FOR 92007-
COLLAR,LEVER
€ 3.50
34
464H0500
ref: 34
H1-D, USE FOR 92007-
WASHER-LOCK,5MM
€ 0.50
35
312B0500
ref: 35
H1-D, USE FOR 92007-
NUT-HEX,5MM
€ 0.50
35
92019014
ref: 35
H1-E/F,KH500-A8
NUT-LOCK,5M/M
€ 2.50
36
110N0625
ref: 36
BOLT-HEX HEAD,6X25
€ 3.50
37
410B0600
ref: 37
WASHER-PLAIN-SMALL,6M
€ 0.50
38
4609401121
ref: 38
H1-D/E/F
HOLDER-CLUTCH LEV,BLK
€ 23.00
38
46094017
ref: 38
KH500-A8
HOLDER,CLUTCH LEVER
€ 23.00
39
46056005
ref: 39
NUT-LOCK
€ 6.00
40
46055006
ref: 40
SCREW-CABLE ADJUST
€ 15.50
41
221B0308A
ref: 41
SCREW-CNTSNK HD,3X8
€ 2.50
42
46089016
ref: 42
H1-D/E
SWITCH ASSEMBLY,LH
€ 22.00
42
46089014
ref: 42
H1-F
SWITCH, L.H
€ 15.00
43
99990530
ref: 43
INCLUDES REF. #S 21,
DIMMER SWITCH KIT A
€ 1.00
44
220B0305A
ref: 44
SCREW-PAN HEAD,3X5
€ 1.00
