CARBURETOR ('80-'81 KE175-D2/D3

ref

part #

description

quantity

1

490061169
ref: 1

BOOT,CARBURETOR

€ 22.00

2

92036018
ref: 2

CIRCLIP

€ 2.50

3

160011266
ref: 3

CARBURETOR

€ 189.00

4

110091178
ref: 4

GASKET,FLOAT CHAMBER

€ 7.00

5

160311011
ref: 5

FLOAT

€ 35.00

6

920551076
ref: 6

RING-O

€ 6.00

7

140251198
ref: 7

COVER,FLOAT CHAMBER

€ 9.00

8

920631028
ref: 8

JET-MAIN,#A102.5R

€ 10.00

8

920631035
ref: 8
(RACING USE ONLY)

MAIN JET,#97.5R

€ 10.00

8

920631033
ref: 8
(RACING USE ONLY)

JET-MAIN,#A100R

€ 17.00

8

920631042
ref: 8
(RACING USE ONLY)

JET-MAIN,#A105R

€ 10.50

8

92063073
ref: 8
(RACING USE ONLY)

JET-MAIN,#107.5R

€ 9.50

9

16034001
ref: 9

WASHER-MAIN JET

€ 2.50

10

160171050
ref: 10

JET,NEEDLE#0-6

€ 16.50

11

920641026
ref: 11

PILOT JET,#22.5

€ 9.00

12

131691224
ref: 12

SPRING PLATE,STARTER

€ 10.50

13

160301011
ref: 13

VALVE-FLOAT,2.0

€ 29.50

14

16032003
ref: 14

FLOAT PIN

€ 4.00

15

220B0408
ref: 15

SCREW-PAN-CROS

€ 0.50

16

131691190
ref: 16

PLATE,LOCK

€ 3.50

17

131691226
ref: 17

PLATE,TUBE CLAMP

€ 5.00

18

920591116
ref: 18

TUBE,3X5X100

€ 6.00

19

220B0416
ref: 19

SCREW-PAN-CROS

€ 2.00

20

160211012
ref: 20

SCREW-THROTTLE STOP

€ 10.50

21

920811152
ref: 21

SPRING,THROTTLE ADJST

€ 4.00

22

92055044
ref: 22

'O' RING

€ 7.00

23

16004018
ref: 23

CAP-CHAMBER,MIXING

€ 15.00

24

16002014
ref: 24

ADJUSTER-CABLE

€ 8.00

25

140251197
ref: 25

COVER,THROTTLE VALVE

€ 5.50

26

16003006
ref: 26

NUT-CABLE ADJUST LOCK

€ 4.50

27

16006023
ref: 27

SPRING,THROTTLE VALV

€ 10.00

28

16008010
ref: 28

CLAMP,E-TYPE

€ 5.00

29

920591755
ref: 29

TUBE,3X5X300

€ 6.00

30

160251043
ref: 30

THROTTLE VALVE,CA2.0

€ 46.00

31

16063004
ref: 31

LEVER,STARTER PLUNGER

€ 22.50

32

92059130
ref: 32

PIPE,FUEL

€ 15.50

33

92037072
ref: 33

CLAMP,TUBE

€ 4.00

34

160161011
ref: 34

PLUNGER,STARTER

€ 18.50

35

670B1509
ref: 35

O RING,9MM

€ 1.00

36

131591010
ref: 36

CONNECTOR,THROTTLE

€ 9.00

37

16033031
ref: 37

SCREW, PAN HEAD, 3X14

€ 3.50

38

920221024
ref: 38

WASHER,THROTTLE VALVE

€ 4.50

39

16039015
ref: 39

CAP,STARTER PLUNGER

€ 4.50

40

16012019
ref: 40

CAP-STARTER PLUNGER

€ 12.50

41

920811181
ref: 41

SPRING,STARTER PLUNG

€ 3.00

42

920271103
ref: 42

RING,JET NEEDLE

€ 4.50

43

920811072
ref: 43

NEEDLE JET SPRING

€ 2.50

44

160071011
ref: 44

THROTTLE VALVE PLATE

€ 9.00

45

160091053
ref: 45

JET,NEEDLE,5CT34

€ 8.50

46

461F0400
ref: 46

WASHER-SPRING,4MM

€ 0.50
