FOOTRESTS/STANDS/BRAKE PEDAL

ref

part #

description

quantity

1

34003003
ref: 1
'69-'70

BAR,FOOTREST L.H

€ 9.00

1

34003012
ref: 1

FOOTREST BAR,LH

€ 29.50

2

34003004
ref: 2
'68

BAR,FOOTREST R.H

€ 9.00

2

34003014
ref: 2
'69-'70

FOOTREST BAR,RH

€ 30.50

3

34024017
ref: 3

SIDE STAND

€ 59.50

4

92076010
ref: 4
'68

RUBBER-FOOTREST

€ 6.00

4

92076006
ref: 4
'69-'70

DAMPER,STEP

€ 10.00

5

34006002
ref: 5

SPRING-FOOTREST PEG

€ 3.00

6

92022049
ref: 6

WASHER-FOLDING PEG

€ 2.00

7

92022085
ref: 7

WASHER,15.3X24X1.2

€ 2.50

8

34025001
ref: 8

SPRING,SIDE STAND

€ 9.50

9

43005005
ref: 9

SPRING-BRAKE PEDAL

€ 3.00

10

480J1600
ref: 10

CIRCLIP-TYPE-C,16MM

€ 2.50

11

113G1240
ref: 11
USE FOR 34003-003,00

BOLT-HEX HEAD,12X40

€ 6.00

11

113G1240
ref: 11
USE FOR 34003-003,00

BOLT-HEX HEAD,12X40

€ 6.00

11

113G1263
ref: 11
USE FOR 34003-012,01

BOLT HEX HEAD 12X63

€ 2.50

11

113G1263A
ref: 11
USE FOR 34003-012,01

BOLT HEX HEAD 12X63

€ 3.00

12

461F1200
ref: 12

WASHER-SPRING,12MM

€ 0.50

13

550D3030
ref: 13

PIN-COTTER,3.0X30

€ 1.50

14

112G1030
ref: 14

BOLT UPSET

€ 4.50

15

315B1000
ref: 15

NUT,10MM

€ 0.50

16

43001022
ref: 16

BRAKE PEDAL

€ 46.50

17

43004008
ref: 17

BRAKE PEDAL SHAFT

€ 17.50

18

314G1200A
ref: 18

NUT,12MM

€ 2.50

18

314B1200
ref: 18
I.S.O.

NUT-HEX-FINE

€ 1.00

19

34011025
ref: 19
'68

MAIN STAND

€ 93.50

19

34011025
ref: 19
'69-'70

MAIN STAND

€ 93.50

20

34019008
ref: 20

SHAFT-STAND,CNT

€ 14.50

21

34023005
ref: 21
'68

SPRING-MAIN STAND

€ 6.50

21

34023005
ref: 21
'69-'70

SPRING-MAIN STAND

€ 6.50

22

430105003
ref: 22
'68

BRAKE ROD ASSY

€ 15.00

22

43010008
ref: 22
'69-'70

BRAKE ROD ASSEMBLY

€ 17.00

23

43008001
ref: 23

REAR BRAKE TORQUE SPRING

€ 1.50

24

92043039
ref: 24

PIN,BRAKE ROD

€ 4.50

25

92015042
ref: 25

NUT-BRAKE ROD ADJUST

€ 4.00

26

410B0500
ref: 26

WASHER-PLAIN-SMALL,5M

€ 0.50

27

550D2015
ref: 27

PIN-COTTER,2.0X15

€ 1.00
