FRONT FORK

ref

part #

description

quantity

1

44001201
ref: 1

FRONT FORK

€ 1,935.00

2

44032012
ref: 2

BOLT,FORK TOP

€ 10.00

3

44046023
ref: 3

O RING,FORK TOP BL

€ 3.00

4

920011063
ref: 4

BOLT,HEX HEAD,8X40

€ 6.50

5

461F0800
ref: 5

WASHER-SPRING,8MM

€ 0.50

6

44041038
ref: 6

BOLT-HEX HEAD,8X55

€ 5.50

7

44039064
ref: 7

HEAD,STEERING STEM

€ 71.00

8

920151124
ref: 8

NUT,LOCK,8MM

€ 3.50

9

44064026
ref: 9

CAP,FORK COVER

€ 5.50

10

44033080
ref: 10

COVER, L.H FORK

€ 45.50

11

92047006
ref: 11

CONE-STRNG STEM

€ 11.00

12

44064021
ref: 12

CAP,FORK COVER

€ 14.00

13

92022297
ref: 13

WASHER,FORK COVER

€ 6.00

14

92075240
ref: 14

DAMPER RUBBER,FK COV

€ 3.00

15

44037077
ref: 15

STEM,STEERING

€ 295.00

16

920011007
ref: 16

BOLT,10X50

€ 5.50

17

461F1000
ref: 17

WASHER-SPRING,10MM

€ 0.50

18

44026061
ref: 18

SPRING,FORK

€ 26.50

19

440131001
ref: 19

FORK INNER TUBE

€ 138.00

20

44034080
ref: 20

COVER, R.H FORK

€ 84.00

21

440061002
ref: 21

FORK OUTER TUBE,RH

€ 156.50

22

110B0608
ref: 22

BOLT-HEX HEAD,6X8

€ 0.50

23

44045047
ref: 23

GASKET,DRAIN PLUG (NAS)

€ 6.00

24

920931063
ref: 24

SEAL,FORK

€ 19.50

25

44043057
ref: 25

RING,OIL SEAL STOPER

€ 4.00

26

920491077
ref: 26

OIL SEAL,FORK

€ 13.50

27

44025003
ref: 27

RING,PISTON

€ 7.00

28

440261001
ref: 28

FORK SPRING,SHORT

€ 3.00

29

44022035
ref: 29

CYLINDER,FORK

€ 41.00

30

440051002
ref: 30

FORK OUTER TUBE,LH

€ 114.50

31

44045051
ref: 31

GASKET,FORK CYLINDER (NAS)

€ 4.00

32

44041078
ref: 32

BOLT, FORK CYLINDER

€ 6.50

33

44063010
ref: 33

HOLDER,FRONT AXLE

€ 23.00

34

172G0830
ref: 34

STUD,8X30

€ 1.50

35

92017013
ref: 35

NUT,LOCK,8MM

€ 5.50

36

27016043
ref: 36

LOCK ASSY,STEERING

€ 29.00

37

440651001
ref: 37

FORK BUSHING

€ 9.00

38

92014016
ref: 38

SCREW, SEAT LOCK

€ 3.50

39

920261005
ref: 39

SPACER,FORK

€ 8.50
