CHASSIS ELECTRICAL EQUIPMENT ('7
F9 1972 USA CANADA
Chassis electrical equipment ('7 diagram F9 1972 USA CANADA
CHASSIS ELECTRICAL EQUIPMENT ('7 F9 1972 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
1
26001069
ref: 1
WIRING HARNESS-MAIN
€ 103.50
1
26001078
ref: 1
UNAVAILABLE IN PRICE BOOK
€ 0.00
2
26002027
ref: 2
WIRING HARNWSS-REAR
€ 10.00
2
26002029
ref: 2
WIRING HARNESS-REAR
€ 8.00
3
26010017
ref: 3
WIRE-BATTERY GROUND
€ 2.50
3-1
26011093
ref: 3-1
WIRE-LEAD
€ 6.00
4
26011042
ref: 4
WIRE-LEAD
€ 3.00
5
26004008
ref: 5
FUSE-ASSY
€ 13.00
6
26006003
ref: 6
FUSE 10A
€ 3.00
7
27010018
ref: 7
SWITCH-BRAKE LAMP
€ 23.00
8
27011004
ref: 8
SPRING-BRAKE LAMP SW
€ 2.50
9
26012021
ref: 9
BATTERY 6V 2AH
€ 28.00
9
26012035
ref: 9
BATTERY,YUA,6N4B-2A-3
€ 73.50
10
23040032
ref: 10
OPTION
LAMP-FRNT TURN SIGNAL
€ 26.00
11
23043030
ref: 11
OPTION
LAMP-REAR TURN SIGNA
€ 22.50
12
410B1000
ref: 12
OPTION
WASHER-PLAIN-SMALL,10
€ 0.50
13
461F1000
ref: 13
OPTION
WASHER-SPRING,10MM
€ 0.50
14
315B1000
ref: 14
OPTION
NUT,10MM
€ 0.50
15
222B0315A
ref: 15
OPTION
SCREW-OVL CNTSNK,3X15
€ 2.50
16
23048011
ref: 16
OPTION
LENS-SIGNAL LAMP
€ 15.50
17
92069042
ref: 17
OPTION
BULB,6V 8W
€ 3.00
18
27002009
ref: 18
OPTION
RELAY-TURN SIGNAL
€ 23.50
19
220B0616
ref: 19
OPTION
SCREW-PAN HEAD,6X16
€ 2.50
20
410B0600
ref: 20
OPTION
WASHER-PLAIN-SMALL,6M
€ 0.50
21
461F0600
ref: 21
OPTION
WASHER-SPRING,6MM
€ 0.50
22
27023001
ref: 22
OPTION
BRACKET-SIGNAL RELAY
€ 2.00
23
26001054
ref: 23
OPTION
WIRING HARNESS-MAIN
€ 38.50
24
26011058
ref: 24
OPTION
WIRE-LEAD
€ 4.00
25
92072030
ref: 25
F9A
BAND,SHORT
€ 3.00
26
92072031
ref: 26
F9A
BAND,MIDDLE
€ 3.00
27
92072032
ref: 27
F9A
BAND,LONG
€ 3.00
28
27003062
ref: 28
F9
HORN
€ 28.50
28
27003062
ref: 28
F9
HORN
€ 28.50
29
112G0620
ref: 29
F9
BOLT 6X20
€ 1.00
30
411B0600
ref: 30
F9
WASHER-PLAIN,6MM
€ 0.50
31
461F0600
ref: 31
F9
WASHER-SPRING,6MM
€ 0.50
32
311B0600
ref: 32
NUT,6MM
€ 0.50
33
27003057
ref: 33
F9-A
HORN
€ 83.00
33
27003057
ref: 33
F9-A
HORN
€ 83.00
