GEAR CHANGE MECHANISM

ZX750-P8 2003 USA CALIFORNIA CANADA

Gear change mechanism diagram ZX750-P8 2003 USA CALIFORNIA CANADA

GEAR CHANGE MECHANISM ZX750-P8 2003 USA CALIFORNIA CANADA
GEAR CHANGE MECHANISM ZX750-P8 2003 USA CALIFORNIA CANADA
GEAR CHANGE MECHANISM ZX750-P8 2003 USA CALIFORNIA CANADA
prices are in EUR
ref
part #
description
quantity
130
130S0620
ref: 130
BOLT-FLANGED,6X20,BLA
130S0620
€ 2.50
480
480J1300
ref: 480
CIRCLIP-TYPE-C,13MM
480J1300
€ 2.50
13161
131611223
ref: 13161
LEVER-COMP-CHANGE SHA
131611223
€ 68.50
13236
132361204
ref: 13236
LEVER-COMP,CHANGE PED
132361204
€ 47.00
13236A
132361253
ref: 13236A
LEVER-COMP,POSITION
132361253
€ 7.50
13242
132421278
ref: 13242
LEVER-ASSY-CHANGE,LIN
132421278
€ 26.00
39110
391101100
ref: 39110
ROD-ASSY-TIE
391101100
€ 12.50
92002
920021778
ref: 92002
BOLT,SOCKET,6X16
920021778
€ 3.00
92015
920151443
ref: 92015
NUT
920151443
€ 2.50
92015A
920151444
ref: 92015A
NUT
920151444
€ 3.00
92022
920221496
ref: 92022
WASHER,13.3X20X1
920221496
€ 2.50
92022A
920221827
ref: 92022A
WASHER,6X12.8X1.2
920221827
€ 3.00
92026
920261217
ref: 92026
SPACER
920261217
€ 3.50
92143
921431498
ref: 92143
COLLAR,RETURN SPRING
921431498
€ 7.00
92144
921441628
ref: 92144
SPRING,CHANGE SHAFT R
921441628
€ 6.50
92144A
921441873
ref: 92144A
SPRING,LEVER POSITION
921441873
€ 5.00
92144B
921441975
ref: 92144B
SPRING,CHANGE LEVER
921441975
€ 3.00
92152
921521075
ref: 92152
COLLAR
921521075
€ 2.50
92160
921601036
ref: 92160
DAMPER,CHANGE PEDAL
921601036
€ 3.50
