CARBURETOR ASSY ('80-'81 C1/C2)
KZ550C4 LTD 1983 USA CANADA
Carburetor assy ('80-'81 c1/c2) diagram KZ550C4 LTD 1983 USA CANADA
CARBURETOR ASSY ('80-'81 C1/C2) KZ550C4 LTD 1983 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
1
160011210
ref: 1
CARBURETOR ASSEMBLY
€ 826.00
1
160011285
ref: 1
USE FOR CANADA MARKE
CARBURETOR ASSY
€ 1,742.00
2
160011255
ref: 2
USE FOR 16001-1210
CARBURETOR,OUTSIDE,LH
€ 190.50
2
160011305
ref: 2
USE FOR 16001-1285
CARBURETOR,L.H,OUTSID
€ 245.50
3
160011254
ref: 3
USE FOR 16001-1210
CARBURETOR,INSIDE,LH
€ 190.50
3
160011306
ref: 3
USE FOR 16001-1285
CARBURETOR,L.H,INSIDE
€ 245.50
4
160011253
ref: 4
USE FOR 16001-1210
CARBURETOR,INSIDE,RH
€ 190.50
4
160011307
ref: 4
USE FOR 16001-1285
CARBURETOR,R.H,INSIDE
€ 245.50
5
160011252
ref: 5
USE FOR 16001-1210
CARBURETOR,OUTSIDE,RH
€ 182.00
5
160011308
ref: 5
USE FOR 16001-1285
CARBURETOR,R.H,OUTSID
€ 234.00
6
110341588
ref: 6
BRACKET,CARBURETOR
€ 80.50
7
221B0616
ref: 7
SCREW-CNTSNK HD,6X16
€ 0.50
8
160411021
ref: 8
SHAFT,CHOKE LEVER
€ 21.00
9
600A0500
ref: 9
BALL-STEEL,5/32
€ 0.50
10
920811195
ref: 10
SPRING,CHOKE LEVER
€ 1.50
11
920811191
ref: 11
SPRING,CHOKE LEVER
€ 4.50
12
490601002
ref: 12
CAM,CHOKE
€ 8.00
13
411B0600
ref: 13
WASHER-PLAIN,6MM
€ 0.50
14
220B0408
ref: 14
SCREW-PAN-CROS
€ 0.50
15
461F0600
ref: 15
WASHER-SPRING,6MM
€ 0.50
16
920221168
ref: 16
WASHER,CHOKE LEVER SP
€ 3.00
17
920221169
ref: 17
WASHER,CHOKE LEVER
€ 3.00
18
131681053
ref: 18
LEVER
€ 12.50
19
920091081
ref: 19
SCREW,TIMING LEVER
€ 6.50
20
920811192
ref: 20
SPRING,TIMING LEVER
€ 3.00
21
110341590
ref: 21
BRACKET,THROTTLE STOP
€ 10.50
22
920091082
ref: 22
SCREW,TIMING LEVER
€ 3.00
23
920091083
ref: 23
SCREW,THROTTLE OPEN
€ 2.50
24
312B0500
ref: 24
NUT-HEX,5MM
€ 0.50
25
160411012
ref: 25
SHAFT,THROTTLE
€ 65.00
26
110341591
ref: 26
PLATE,THROTTLE SHAFT
€ 5.50
27
220B0514
ref: 27
ACREW-PAN HEAD,5X14
€ 2.50
28
461F0500
ref: 28
WASHER-SPRING,5MM
€ 0.50
29
131681054
ref: 29
LEVER ASSY,THROTTLE
€ 27.00
30
131681055
ref: 30
LEVER ASSY,THROTTLE
€ 27.50
31
221B0514A
ref: 31
SCREW-CNTSNK HD,5X14
€ 2.50
32
110341592
ref: 32
BRACKET,THROTTLE CABL
€ 13.00
33
220B0614
ref: 33
SCREW-PAN HEAD,6X14
€ 2.00
34
160211017
ref: 34
SCREW,THROTTLE ADJUST
€ 12.00
35
920811193
ref: 35
SPRING,ADJUST SCREW
€ 4.50
36
920931033
ref: 36
SEAL,THROTTLE SHAFT
€ 10.00
37
920931034
ref: 37
CAP,THROTTLE SHAFT
€ 8.50
38
920811381
ref: 38
SPRING,THROTTLE RETRN
€ 9.50
39
110341593
ref: 39
BRACKET,THROTTLE SPR
€ 7.50
40
920051020
ref: 40
FITTING,FUEL,T-TYPE
€ 20.50
41
670B1507
ref: 41
O RING,7MM
€ 1.00
42
920051021
ref: 42
FITTING,FUEL,I-TYPE
€ 20.00
43
920591098
ref: 43
HOSE,FUEL,7X12X180
€ 19.50
44
920371158
ref: 44
CLAMP,FUEL HOSE
€ 4.50
45
920591099
ref: 45
HOSE,AIR VENT,4.5X30
€ 3.50
46
920591100
ref: 46
HOSE,AIR VENT,4.5X300
€ 11.50
47
920591101
ref: 47
HOSE,NEGATIVE,5.4X280
€ 20.00
48
920371159
ref: 48
CLAMP,NEGATIVE HOSE
€ 2.00
49
920591102
ref: 49
HOSE,OVERFLOW,3.5X550
€ 16.50
50
482J3000
ref: 50
CIRCLIP,3M/M
€ 2.00
51
920091080
ref: 51
SCREW,COUNTERSUNK HD
€ 2.50
52
92037134
ref: 52
CLAMP,OVER FLOW PIPE
€ 7.50
