ROCKER ARMS/VALVES ('75 S)

KZ400S SPECIAL 1975 USA CANADA

Rocker arms/valves ('75 s) diagram KZ400S SPECIAL 1975 USA CANADA

ROCKER ARMS/VALVES ('75 S) KZ400S SPECIAL 1975 USA CANADA

ROCKER ARMS/VALVES ('75 S) KZ400S SPECIAL 1975 USA CANADA

prices are in EUR

ref

part #

description

quantity

1

314G0800
ref: 1

NUT,8M/M

€ 1.50

2

92088022
ref: 2

WASHER, LOCK

€ 7.50

3

92055098
ref: 3

RING-O

€ 5.50

4

12020003
ref: 4

SHAFT,ROCKER

€ 13.50

5

12016011
ref: 5

ARM,ROCKER

€ 59.50

6

12011002
ref: 6
-E/NO. 018691

COLLET,VALVE SPRING

€ 16.00

6

12011004
ref: 6
E/NO. 018692 -

COLLET,RETAINER

€ 3.50

7

12009006
ref: 7

RETAINER,VALVE SPRIN

€ 7.50

8

12007013
ref: 8

SPRING,OUTER VALVE

€ 11.00

9

12007014
ref: 9

SPRING,INNER VALVE

€ 11.00

10

92049016
ref: 10

OIL SEAL,RV37129.5

€ 13.50

11

12010006
ref: 11
O.D.=23

SEAT,VALVE INNER SPR

€ 2.00

12

12010005
ref: 12
O.D.=31

SEAT-SPRING,OUTER

€ 4.50

13

490021010
ref: 13
- E/NO. 018691

GUIDE-VALVE,EXHAUST

€ 20.50

13

490021010
ref: 13
E/NO. 018692 -

GUIDE-VALVE,EXHAUST

€ 20.50

13

490021010
ref: 13

GUIDE-VALVE,EXHAUST

€ 20.50

14

92055065
ref: 14

RING-O,VALVE GUIDE

€ 4.50

15

12005006
ref: 15
- E/NO. 018691

VALVE,EXHAUST

€ 37.50

15

12005012
ref: 15
E/NO. 018692 -

VALVE-EXHAUST

€ 41.50

16

12013003
ref: 16
- E/NO. 018691

GUIDE-VALVE,INTAKE

€ 24.00

16

12013003
ref: 16
E/NO. 018692 -

GUIDE-VALVE,INTAKE

€ 24.00

17

12004013
ref: 17
- E/NO. 018691

VALVE,INLET

€ 22.00

17

12004019
ref: 17
E/NO. 018692 -

VALVE,INLET

€ 33.50
