CARBURETOR
KL600A1 1984 EUROPE UK FR GR IT SD ST WG
Carburetor diagram KL600A1 1984 EUROPE UK FR GR IT SD ST WG
CARBURETOR KL600A1 1984 EUROPE UK FR GR IT SD ST WG
×
prices are in EUR
ref
part #
description
quantity
11043
110431336
ref: 11043
BRACKET-B,THROTTLE CA
€ 18.00
13091
130911312
ref: 13091
HOLDER,NEEDLE JET
€ 15.50
14025
140251890
ref: 14025
COVER,MIXING CHAMBER
€ 58.50
14025A
140251903
ref: 14025A
COVER,AIR CUT VALVE
€ 43.00
15001
150011054
ref: 15001
ST
CARBURETOR-ASSY
€ 287.50
15001A
160011960
ref: 15001A
EU, FR, GR, IT, SD,
CARBURETOR
€ 446.00
15001B
160011995
ref: 15001B
WG
CARBURETOR
€ 291.00
16007
160071113
ref: 16007
SEAT-SPRING,DIAPHRAGM
€ 13.50
16009
160091234
ref: 16009
EU, FR, GR, IT, SD,
NEEDLE-JET,N24B
€ 20.00
16009A
160091235
ref: 16009A
ST, WG
NEEDLE-JET,N23B
€ 19.00
16012
160121055
ref: 16012
CAP-STARTER PLUNGER
€ 17.50
16014
160141053
ref: 16014
SCREW-PILOT AIR
€ 15.50
16016
160161057
ref: 16016
PLUNGER
€ 41.00
16017
160171253
ref: 16017
JET-NEEDLE
€ 36.50
16021
160211109
ref: 16021
SCREW-THROTTLE STOP
€ 31.50
16030
160301057
ref: 16030
VALVE-FLOAT
€ 37.00
16031
160311056
ref: 16031
FLOAT
€ 39.00
35011
350111232
ref: 35011
STAY,AIR CUT VALVE
€ 25.00
43028
430281052
ref: 43028
EU, FR, GR, IT, SD,
DIAPHRAGM,VALVE
€ 175.00
43028A
430281053
ref: 43028A
DIAPHRAGM,5.9MM,AIR C
€ 62.50
43028B
430281055
ref: 43028B
ST
DIAPHRAGM,VALVE
€ 141.00
43028C
430281056
ref: 43028C
WG
DIAPHRAGM,VALVE
€ 110.50
49006
490061165
ref: 49006
BOOT,STARTER PLUNGER
€ 6.50
92005
920051120
ref: 92005
FITTING,L-TYPE
€ 18.50
92009
920091095
ref: 92009
SCREW,DRAIN
€ 10.00
92022
920221003
ref: 92022
WASHER,PLAIN
€ 2.50
92022A
920221587
ref: 92022A
WASHER,THROTTLE STOP
€ 3.00
92037
16044007
ref: 92037
CLIP, FLOAT VALVE
€ 4.00
92037A
920371531
ref: 92037A
CLAMP,TUBE
€ 3.50
92043
920431207
ref: 92043
PIN,FLOAT
€ 6.00
92055
920551002
ref: 92055
O RING,PILOT ADJUST
€ 2.50
92055A
920551053
ref: 92055A
O RING,DRAIN SCREW
€ 3.00
92055B
920551222
ref: 92055B
RING-O,FLOAT CHAMBER
€ 12.50
92055C
920551245
ref: 92055C
RING-O
€ 3.50
92055D
920551246
ref: 92055D
RING-O
€ 3.00
92059
920591380
ref: 92059
TUBE,3.5X6.5X330
€ 8.50
92059A
920591463
ref: 92059A
TUBE,6.5X11.5X150
€ 20.00
92059B
920591465
ref: 92059B
TUBE,6.5X9.5X500
€ 20.50
92063
920631013
ref: 92063
EU, FR, GR, IT, SD,
MAIN JET,#140
€ 9.00
92063A
920631014
ref: 92063A
(OFF ROAD USE ONLY)
MAIN JET,#135
€ 9.50
92063B
920631015
ref: 92063B
EU, FR, GR, IT, SD,
MAIN JET,#138
€ 9.50
92063C
920631016
ref: 92063C
EU, FR, GR, IT, SD,
MAIN JET,#142
€ 9.00
92063D
920631069
ref: 92063D
ST, WG, (OFF ROAD US
MAIN JET,2ND #125
€ 9.50
92063E
920631074
ref: 92063E
ST, WG, (OFF ROAD US
MAIN JET,2ND #128
€ 9.50
92063F
920631075
ref: 92063F
ST, WG
MAIN JET,2ND #130
€ 9.50
92063G
920631076
ref: 92063G
(OFF ROAD USE ONLY)
JET-MAIN,#132
€ 9.50
92064
920641108
ref: 92064
JET-PILOT,#40
€ 11.00
92066
92068006
ref: 92066
RUBBER PLUG
€ 2.50
92081
920811002
ref: 92081
SPRING,PIROT ADJ SCRW
€ 3.50
92081A
920811718
ref: 92081A
SPRING,DIAPHRAGM VALV
€ 18.50
92081B
920811719
ref: 92081B
SPRING,AIR CUT VALVE
€ 8.50
92081C
920811720
ref: 92081C
SPRING,PLUNGER
€ 7.00
92081D
920811721
ref: 92081D
SPRING,THROTTLE STOP
€ 9.00
223
223C0410
ref: 223
SCREW-PAN-WS-CROS
€ 2.50
223A
223C0416
ref: 223A
SCREW-PAN-WS-CROS
€ 2.50
223B
223C0510
ref: 223B
SCREW-PAN-WS-CROS
€ 2.50
225
225C0418
ref: 225
SCREW-PAN-WSP-CROS
€ 2.50
