CAMSHAFTS/CHAIN/TENSIONER
KZ750M1 CSR TWIN 1982 USA / MPH
Camshafts/chain/tensioner diagram KZ750M1 CSR TWIN 1982 USA / MPH
CAMSHAFTS/CHAIN/TENSIONER KZ750M1 CSR TWIN 1982 USA / MPH
×
prices are in EUR
ref
part #
description
quantity
11009
92065096
ref: 11009
GASKET,FUEL COCK (NAS)
€ 3.00
11012
12064003
ref: 11012
CAP,CHAIN TENSIONER
€ 8.50
12044
12044010
ref: 12044
CAM SHAFT,INLET
€ 186.50
12044A
12044020
ref: 12044A
CAM SHAFT,EXHAUST
€ 186.50
12046
12046006
ref: 12046
SPROCKET,CAM SFT,IN
€ 32.50
12046A
12046007
ref: 12046A
SPROCKET,CAM SFT,EX
€ 34.00
12048
12048005
ref: 12048
TENSIONER-ASSY,CAM CH
€ 393.00
12053
12053015
ref: 12053
GUIDE-CHAIN,CAM
€ 58.00
12053A
120531065
ref: 12053A
GUIDE-CHAIN
€ 10.50
13091
14018006
ref: 13091
HOLDER
€ 28.00
13116
131161001
ref: 13116
ROD-PUSH
€ 11.50
92001
920011009
ref: 92001
BOLT,PUSH ROD
€ 14.50
92001A
92003202
ref: 92001A
BOLT
€ 4.00
92001B
92003208
ref: 92001B
BOLT,SPROCKET FITTING
€ 2.50
92015
92015019
ref: 92015
NUT,18MM
€ 4.00
92022
92022320
ref: 92022
WASHER,PLAIN
€ 1.00
92055
92055095
ref: 92055
RING-O
€ 9.50
92057
21070011
ref: 92057
CHAIN,CAMSHAFT,BF05TX
€ 161.00
92081
920811007
ref: 92081
SPRING,PUSH ROD
€ 3.50
92081A
920811008
ref: 92081A
SPRING
€ 2.50
120
120P0614
ref: 120
BOLT,6X14
€ 3.00
551
551A1032
ref: 551
PIN,DOWEL,10X32
€ 2.50
