IGNITION SWITCH/LOCKS/REFLECTORS

KZ440D5 LTD 1983 USA CANADA / BELT DRIVE

Ignition switch/locks/reflectors diagram KZ440D5 LTD 1983 USA CANADA / BELT DRIVE

prices are in EUR

ref

part #

description

quantity

27004

270045113
ref: 27004

SWITCH-ASSY

€ 156.00

27005

270051033
ref: 27005

SWITCH ASSY,IGNITION

€ 144.00

27008

270081034
ref: 27008
(OPTION)

KEY,BLANK

€ 13.00

27008A

270081035
ref: 27008A
(OPTION)

KEY,BLANK

€ 12.50

27010

27010025
ref: 27010

SWITCH,BRAKE LAMP

€ 18.50

27016

270165029
ref: 27016

LOCK ASSY,HELMET

€ 73.50

28012

28012016
ref: 28012

REFLECTOR REFLEX

€ 16.00

92022

920221561
ref: 92022

WASHER,8.5X20X1.6

€ 2.50

92027

920271135
ref: 92027

COLLAR,IG SWITCH

€ 7.00

92075

920751119
ref: 92075

DAMPER,IG SWITCH

€ 4.00

92075A

92094011
ref: 92075A

DAMPER,REFLECTOR

€ 3.00

92081

27011021
ref: 92081

SPRING,BRAKE LAMP SW

€ 15.50

120

120P0845
ref: 120

BOLT,ALLEN,8X45

€ 3.00

461

461F0800
ref: 461

WASHER-SPRING,8MM

€ 0.50
