REAR HUB/BRAKE/CHAIN
KL250A1 KLR250 1978 CANADA
Rear hub/brake/chain diagram KL250A1 KLR250 1978 CANADA
REAR HUB/BRAKE/CHAIN KL250A1 KLR250 1978 CANADA
×
prices are in EUR
ref
part #
description
quantity
1
410341015
ref: 1
DRUM ASSY,REAR BRAKE
€ 320.50
2
481J3500
ref: 2
CIRCLIP-TYPE-C,35MM
€ 1.00
3
601B6202
ref: 3
BEARING-BALL,#6202C3
€ 14.50
4
601B6202U
ref: 4
BEARING-BALL,#6202UC3
€ 19.50
5
920271099
ref: 5
COLLAR,L=86
€ 13.00
6
920751068
ref: 6
DAMPER,SHOCK,RR HUB
€ 34.50
7
410351018
ref: 7
PANEL ASSY,RR BRAKE
€ 173.00
8
112G0622
ref: 8
BOLT-UPSET
€ 2.50
9
410B0600
ref: 9
WASHER-PLAIN-SMALL,6M
€ 0.50
10
410481012
ref: 10
SHOE,BRAKE (MCA)
€ 26.00
11
920811766
ref: 11
SPRING,BRAKE SHOE
€ 5.50
12
920811550
ref: 12
SPRING,BRAKE SHOE
€ 6.00
13
410501011
ref: 13
CAM-BRAKE
€ 25.00
14
41051001
ref: 14
DUST SHIELD-BRAKE CAM
€ 2.50
15
410531014
ref: 15
LEVER-BRAKE CAM
€ 39.50
16
41085017
ref: 16
INDICATOR,BRAKE SHOE
€ 7.50
17
410681104
ref: 17
AXLE,RR
€ 30.50
18
42045020
ref: 18
NUT,14MM
€ 6.50
19
550D3030
ref: 19
PIN-COTTER,3.0X30
€ 1.50
20
920271100
ref: 20
COLLAR,AXLE,RR,L=21
€ 16.00
21
920271176
ref: 21
COLLAR,L=31
€ 10.50
22
420331010
ref: 22
COUPLING ASSY,RR HUB
€ 134.50
23
420361020
ref: 23
SLEEVE,RR HUB COUPLIN
€ 15.50
24
920331041
ref: 24
CIRCLIP,42MM
€ 4.00
25
601B6004
ref: 25
BEARING-BALL,#6004C3
€ 10.50
26
920041015
ref: 26
STUD,8X17
€ 2.50
27
920151022
ref: 27
NUT, 8MM
€ 0.50
28
92050060
ref: 28
OIL SEAL,RR HUB BRNK
€ 12.00
29
420411053
ref: 29
REAR SPROCKET,40T
€ 36.50
30
920571002
ref: 30
EK520SH-G
CHAIN ASSY,DRV,JE-96L
€ 47.00
31
920581001
ref: 31
JOINT-CHAIN
€ 4.50
