OWNER TOOLS

H2A MACH IV 1973 CANADA

Owner tools diagram H2A MACH IV 1973 CANADA

OWNER TOOLS H2A MACH IV 1973 CANADA

OWNER TOOLS H2A MACH IV 1973 CANADA

prices are in EUR

ref

part #

description

quantity

1

56007028
ref: 1

TOOL KIT

€ 61.00

2

56008008
ref: 2

BAG,TOOL

€ 16.50

3

92106002
ref: 3

GRIP-SCRE DRIVER

€ 7.00

4

92107005
ref: 4

SCREW DRIVER-#3 PHLIP

€ 7.00

5

921071052
ref: 5

TOOL-DRIVER

€ 6.50

6

92112003
ref: 6

PLIERS,150MM

€ 18.00

7

92126001
ref: 7

TOOL-WRENCH,OPEN END,

€ 9.00

8

92126002
ref: 8

WRENCH-OPEN END,12X13

€ 7.50

9

921101153
ref: 9

TOOL-WRENCH,OPEN END,

€ 12.50

10

92126007
ref: 10

WRENCH,OPEN END,19X22

€ 9.00

11

921101147
ref: 11

TOOL-WRENCH,BOX END,2

€ 15.00

12

92111004
ref: 12

BAR-BOX WRENCH

€ 8.00

13

92110007
ref: 13

WRENCH-BOX,10MM

€ 5.50

14

92110012
ref: 14

TOOL-WRENCH,BOX,21MM

€ 13.00

15

92111005
ref: 15

TOOL-BAR,SPARK PLUG W

€ 3.50

16

92108007
ref: 16

ADJUSTER-SHOCK ABSVR

€ 8.50

17

92104002
ref: 17

LIQUID GASKET

€ 69.50

18

57001258
ref: 18

PULLER,ROTOR

€ 19.50
