prices are in EUR
ref
part #
description
quantity
1
CAP,RUBBER
2
CARBURETOR COVER,SILVER
2
CARBURETOR COVER,METALLIC CLEAR
2
CARBURETOR COVER,FLAT BLACK
3
GASKET-CARB COVER (MCA)
4
COVER-OIL PUMP
4
OIL PUMP COVER,FLAT BLACK
5
SCREW-PAN HEAD,6X30
6
SCREW-PAN HEAD,6X25
7
SCREW-PAN HEAD,6X35
8
OIL SEAL,TB14257
9
ENGINE COVER,RH,FLAT BLACK
10
SCREW-PAN HEAD,6X45
11
GASKET,CLUTCH COVER (NAS)
12
PLUG,OIL FILLER
13
'O' RING-OIL FIL PLUG
14
DRAIN-FUEL
15
PLUG-OIL DRAIN
16
GASKET, 10,5X16X1 (NAS)
17
ENGINE COVER,LH,BUFF
17
ENGINE COVER,LH,BUFF
17
ENGINE COVER,LH,FLAT BLACK
17
ENGINE COVER,LH,FLAT BLACK
19
ENGINE COVER CAP GASKET,LH (MCA)
20
COVER-BRK POINT,CR
21
GASKET-BREAKER COVER (MCA)
22
SCREW-PAN HEAD,6X65
23
SCREW-PAN HEAD,6X12
24
WASHER,6.1X12X1
25
SEAL-OIL
26
OIL SEAL,SC38556
27
ENGINE COVER CAP ASSEMBLY,LH
27
ENGINE COVER CAP ASSEMBLY,BUFF
28
BEARING-BALL,#6005C3
29
BALL-STEEL,1/4
30
SPRING
31
ENGINE COVER CAP PLUG,LH
32
NUT,6MM
33
WASHER-SPRING,6MM
34
LEVER,A
35
RETAINER SHIFT ROD
36
CIRCLIP-TYPE-E,4MM
37
WASHER,WAVE
38
SHIFT LEVER SHAFT ASSEMBLY
39
OIL SEAL,VC8144
40
WASHER-PLAIN-SMALL,8M
41
PIN,DOWEL,10X8.2X14
42
CHANGE CABLE SPRING
43
CAP-CARBURETOR
44
HOLDER-CARBURETOR CAP
45
SCREW-PAN-CROS,5X10
46
BOOT,CARBURETOR CAP
