FRAME FITTINGS

ZX636D6F ZX6R 2006 USA CALIFORNIA CANADA

Frame fittings diagram ZX636D6F ZX6R 2006 USA CALIFORNIA CANADA

FRAME FITTINGS ZX636D6F ZX6R 2006 USA CALIFORNIA CANADA
FRAME FITTINGS ZX636D6F ZX6R 2006 USA CALIFORNIA CANADA
FRAME FITTINGS ZX636D6F ZX6R 2006 USA CALIFORNIA CANADA
prices are in EUR
ref
part #
description
quantity
130
130L0630
ref: 130
BOLT-FLANGED
130L0630
€ 2.00
11053
110531404
ref: 11053
BRACKET,REAR SIGNAL L
110531404
€ 31.00
11053A
110531405
ref: 11053A
BRACKET,REAR SIGNAL L
110531405
€ 29.50
11053B
110531538
ref: 11053B
BRACKET,REAR FLAP
€ 31.00
11053C
110531664
ref: 11053C
BRACKET,RELAY BOX
110531664
€ 29.00
11053D
110531701
ref: 11053D
BRACKET
110531701
€ 13.50
11053E
110531702
ref: 11053E
BRACKET
110531702
€ 13.50
11053F
110531721
ref: 11053F
BRACKET,FRONT SEAT
€ 77.00
14091
140910362
ref: 14091
COVER,REAR SIGNAL LAM
140910362
€ 8.00
14091A
140910363
ref: 14091A
COVER,REAR SIGNAL LAM
140910363
€ 7.00
35063
350630144
ref: 35063
STAY,RR,LH
350630144
€ 110.50
35063A
350630145
ref: 35063A
STAY,RR,RH
350630145
€ 103.00
92002
920021175
ref: 92002
BOLT,SOCKET,6X14
920021175
€ 3.00
92015
920151757A
ref: 92015
NUT,5MM
920151757A
€ 5.00
92022
920221160
ref: 92022
WASHER,7X24X1.6
920221160
€ 2.50
92027
920271450
ref: 92027
COLLAR,L=13.1,BLACK
920271450
€ 4.00
92075
920751690
ref: 92075
DAMPER,10X24X12
920751690
€ 3.00
92075A
920751808
ref: 92075A
DAMPER,6X10X15
920751808
€ 1.50
92150
921501760
ref: 92150
BOLT,SOCKET,8X20
921501760
€ 4.50
92153
921530410
ref: 92153
BOLT,SOCKET,6X10
921530410
€ 2.00
92153A
921530816
ref: 92153A
BOLT,6X18
921530816
€ 1.50
92153B
921531244
ref: 92153B
BOLT,SOCKET,5X16
921531244
€ 1.50
92161
921610046
ref: 92161
DAMPER
921610046
€ 6.50
92172
921720175
ref: 92172
SCREW,TAPPING,5X16
921720175
€ 1.00
