CLUTCH
KX125-E2 1987 EUROPE UK AL
Clutch diagram KX125-E2 1987 EUROPE UK AL
CLUTCH KX125-E2 1987 EUROPE UK AL
×
prices are in EUR
ref
part #
description
quantity
13081
130811187
ref: 13081
CLUTCH-ASSY
€ 344.00
13086
130861056
ref: 13086
WHEEL-CLUTCH
€ 33.00
13087
130871060
ref: 13087
HUB-CLUTCH
€ 61.50
13088
130881058
ref: 13088
PLATE-FRICTION (NAS)
€ 14.00
13089
130891063
ref: 13089
PLATE-CLUTCH (NAS)
€ 8.50
13091
130911011
ref: 13091
HOLDER,CLUTCH
€ 14.50
13091A
130911134
ref: 13091A
HOLDER,CLUTCH PUSHER
€ 9.50
13095
130951117
ref: 13095
HOUSING-COMP-CLUTCH
€ 415.00
13114
131141008
ref: 13114
PUSHER-CLUTCH
€ 12.50
13236
132361121
ref: 13236
LEVER-COMP,CLUTCH REL
€ 20.50
92002
920021706
ref: 92002
BOLT
€ 3.50
92015
920151549
ref: 92015
NUT,16MM
€ 4.50
92022
920221124
ref: 92022
WASHER,TOOTHED,16.5X3
€ 2.00
92022A
920221290
ref: 92022A
WASHER,7X12.5X0.8
€ 2.00
92022B
920221356
ref: 92022B
WASHER,16.3X29X1.75
€ 4.50
92022C
920221761
ref: 92022C
WASHER,17.3X30X1.4
€ 3.50
92022D
92022304
ref: 92022D
WASHER,PLAIN
€ 2.50
92028
920281325
ref: 92028
BUSHING,17X22X24.7
€ 15.50
92045
92045026
ref: 92045
BEARING,BALL,#627
€ 19.50
92046
920461129
ref: 92046
BEARING-NEEDLE,K22X26
€ 12.50
92046A
920461130
ref: 92046A
BEARING-NEEDLE,K22X26
€ 12.00
92081
920811637
ref: 92081
SPRING,CLUTCH
€ 7.00
112
112G0520
ref: 112
BOLT-UPSET
€ 2.50
670
670B1509
ref: 670
O RING,9MM
€ 1.00
