REAR HUB/BRAKE

ref

part #

description

quantity

1

42031022
ref: 1

AXLE,REAR

€ 43.50

?

42006015
ref: ?
Includes items 2 - 1

REAR BRAKE PANEL ASSEMBLY

€ 187.00

3

410481007
ref: 3

SHOE, BRAKE (MCA)

€ 15.00

4

920811766
ref: 4

SPRING,BRAKE SHOE

€ 5.50

5

112G0630
ref: 5

BOLT-UPSET

€ 1.00

6

42029012
ref: 6

REAR BRAKE CAM LEVER

€ 28.50

7

92055004
ref: 7

RING-O,BRAKE CAM

€ 3.00

8

41052001
ref: 8

WASHER-BRAKE CAM SHT

€ 1.00

9

410B0600
ref: 9

WASHER-PLAIN-SMALL,6M

€ 0.50

10

311B0600
ref: 10

NUT,6MM

€ 0.50

11

41050018
ref: 11

CAM-BRAKE

€ 18.00

?

42005016
ref: ?
Includes items 12 -

REAR BRAKE DRUM ASSEMBLY

€ 272.00

13

601B6302Z
ref: 13

BEARING-BALL,#6302ZC3

€ 22.50

14

42010006
ref: 14

REAR HUB BEARING SPACER

€ 12.00

15

601B6202
ref: 15

BEARING-BALL,#6202C3

€ 14.50

16

42014015
ref: 16

REAR HUB SHOCK DAMPER

€ 22.00

?

42033001
ref: ?
Includes items 12 -

REAR HUB COUPLING ASSEMBLY

€ 151.50

18

42036003
ref: 18

SLEEVE-COUPLING

€ 7.00

19

601B6004
ref: 19

BEARING-BALL,#6004C3

€ 10.50

20

92050009
ref: 20

OIL SEAL-RR BRK DRUM

€ 12.00

21

42037004
ref: 21

OIL SEAL COLLAR

€ 15.50

22

42045009
ref: 22

NUT,20MM

€ 9.00

23

321B1400
ref: 23

NUT-CASTLE,14MM

€ 3.00

24

550D3030
ref: 24

PIN-COTTER,3.0X30

€ 1.50

25

42032013
ref: 25

REAR HUB COLLAR,RH

€ 9.50

26

92001021
ref: 26

BOLT-REAR SPROCKET

€ 3.50

27

311B0800
ref: 27

NUT,8MM

€ 0.50

28

92088004
ref: 28

REAR SPROCKET LOCK WASHER

€ 3.00

29

42041065
ref: 29
S.T.D.

REAR SPROCKET,50T

€ 122.00

29

42041052
ref: 29
OPTION

REAR SPROCKET,54T

€ 136.00

29

42041066
ref: 29
OPTION

REAR SPROCKET,52T

€ 159.50
