MUFFLER(S)

EX500D1 NINJA 500 1994 USA CALIFORNIA CANADA

Muffler(s) diagram EX500D1 NINJA 500 1994 USA CALIFORNIA CANADA

MUFFLER(S) EX500D1 NINJA 500 1994 USA CALIFORNIA CANADA

MUFFLER(S) EX500D1 NINJA 500 1994 USA CALIFORNIA CANADA

prices are in EUR

ref

part #

description

quantity

132

132J1065
ref: 132

BOLT-FLANGED-SMALL

€ 5.00

11009

110091667
ref: 11009

GASKET,EXHAUST PIPE C (NAS)

€ 15.00

11009A

110091865
ref: 11009A

GASKET,MUFFLER CONNEC (NAS)

€ 19.50

11060

110601764
ref: 11060

GASKET,EXHAUST PIPE H (NAS)

€ 7.50

18049

180491402
ref: 18049

PIPE-EXHAUST,LH

€ 168.00

18049A

180491403
ref: 18049A

PIPE-EXHAUST,RH

€ 151.00

18069

180691122
ref: 18069

HOLDER-EXHAUST PIPE

€ 16.50

18090

180901331
ref: 18090
CAUS

BODY-COMP-MUFFLER,LH

€ 354.00

18090A

180901332
ref: 18090A
CAUS

MUFFLER BODY,COMPLETE,RH

€ 285.00

18090B

180901420
ref: 18090B
CN

BODY-COMP-MUFFLER,LH

€ 382.00

18090C

180901421
ref: 18090C
CN

BODY-COMP-MUFFLER,RH

€ 314.50

92015

920151174
ref: 92015

NUT,CAP,8MM,BLACK

€ 3.00

92015A

920151387
ref: 92015A

NUT,FLANGED,10MM

€ 2.50

92037

920371792
ref: 92037

CLAMP,39.5MM

€ 10.00

92092

92092010
ref: 92092

BUSHING-MUFFLER FITT

€ 11.00

92170

921701469
ref: 92170

CLAMP

€ 24.50
