FRAME FITTING

ZR550A1 1983 EUROPE UK FR IT NR SD WG

Frame fitting diagram ZR550A1 1983 EUROPE UK FR IT NR SD WG

prices are in EUR

ref

part #

description

quantity

32029

320291048
ref: 32029

BRACKET,ENGINE,FR,R.H

€ 6.00

32029A

320291184
ref: 32029A

BRACKET-ENGINE,RH

€ 6.00

92001

920011613
ref: 92001

BOLT,FLANGED,8X45

€ 3.00

92001A

920011615
ref: 92001A

BOLT,FLANGED,8X60

€ 4.00

92001B

920011616
ref: 92001B

BOLT,FLANGED,8X65

€ 5.50

92001C

920011617
ref: 92001C

BOLT,FLANGED,10X60

€ 6.50

92001D

920011618
ref: 92001D

BOLT,FLANGED,10X70

€ 7.00

92001E

920011621
ref: 92001E

BOLT,FLANGED,10X180

€ 15.00

92001F

920011677
ref: 92001F

BOLT,FLANGED,10X200,B

€ 12.00

92015

920151188
ref: 92015

NUT,LOCK,10MM,BLACK

€ 4.00

92027

920271399
ref: 92027

COLLAR,L=34

€ 8.50

317

317C0800
ref: 317

NUT-HEX-SMALL,8MM,BLA

€ 0.50

461

461K0800
ref: 461

WASHER-SPRING,8MM,BLA

€ 1.50
