TRANSMISSION ('81-'83 D2/D3/D4/D

KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

Transmission ('81-'83 d2/d3/d4/d diagram KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

TRANSMISSION ('81-'83 D2/D3/D4/D KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

TRANSMISSION ('81-'83 D2/D3/D4/D KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

prices are in EUR

ref

part #

description

quantity

13127

131271004
ref: 13127

SHAFT,DRIVE,13T

€ 109.50

13128

131281015
ref: 13128

SHAFT-TRANSMISSION OU

€ 256.50

13129

131291054
ref: 13129

3RD-4TH GEAR,DRIVE

€ 80.50

13129A

131291055
ref: 13129A

TOP GEAR,DRIVE SHAFT

€ 65.00

13129B

131291056
ref: 13129B

LOW GEAR,OUTPUT SHAFT

€ 61.00

13129C

131291058
ref: 13129C

3RD GEAR,OUTPUT SHAFT

€ 62.00

13129D

131291059
ref: 13129D

4TH GEAR OUTPUT

€ 47.50

13129E

131291060
ref: 13129E

5TH GEAR,OUTPUT SHAFT

€ 67.50

13129F

131291061
ref: 13129F

TOP GEAR,OUTPUT SHAFT

€ 40.00

13129G

131291062
ref: 13129G

2ND GEAR,DRIVE SHAFT

€ 30.00

13129H

131291172
ref: 13129H

2ND GEAR,OUTPUT,28T

€ 56.00

13129I

131291277
ref: 13129I

GEAR,INPUT5TH,23T

€ 67.00

13144

131441035
ref: 13144

SPROCKET-OUTPUT,22T

€ 82.50

13144A

131441065
ref: 13144A
SUBSTITUTES 13144-10

SPROCKET-OUTPUT,24T

€ 67.50

13144B

131441065
ref: 13144B

SPROCKET-OUTPUT,24T

€ 67.50

13144C

131441065
ref: 13144C

SPROCKET-OUTPUT,24T

€ 67.50

92015

920151254
ref: 92015

NUT,20MM

€ 10.50

92022

92022112
ref: 92022

WASHER,20.5X30X1,STEE

€ 6.00

92022A

920221170
ref: 92022A

WASHER,CLAW

€ 3.50

92022B

92022144
ref: 92022B

SHIM-KICK SHAFT

€ 4.50

92022C

92022159
ref: 92022C

WASHER-THRUST,25MM

€ 5.50

92022D

92024033
ref: 92022D

WASHER,TOOTHED,25.5X3

€ 4.50

92022E

92024038
ref: 92022E

WASHER-LOCK

€ 4.00

92026

92026079
ref: 92026

WASHER,30X38X1

€ 6.00

92027

92027288
ref: 92027

COLLAR,25X32X23.5

€ 22.50

92027A

92027289
ref: 92027A

COLLAR

€ 10.00

92028

920281002
ref: 92028

BUSHING,TOP DRIVE

€ 26.00

92028A

920281268
ref: 92028A

BUSHING,OUTPUT GEAR

€ 21.00

92028B

920281177
ref: 92028B

BUSHING,2ND GEAR

€ 10.00

92028C

92028155
ref: 92028C

BUSHING,DRIVE SHAFT

€ 9.50

92033

92033015
ref: 92033

CIRCLIP

€ 2.50

92033A

92033026
ref: 92033A

CIRCLIP

€ 6.00

92045

92045031
ref: 92045

BEARING-BALL,5205ANX4

€ 49.50

92046

92046044
ref: 92046

BEARING-NEEDLE,20R251

€ 23.00

92048

920481001
ref: 92048

RACE,OUTPUT AND DRIVE

€ 13.00

92049

92050024
ref: 92049

OIL SEAL SC325210

€ 5.00

92055

92055035
ref: 92055

O RING

€ 3.00

600

600A0500
ref: 600

BALL-STEEL,5/32

€ 0.50
