CRANKCASE ('80 D1)

KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

Crankcase ('80 d1) diagram KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

CRANKCASE ('80 D1) KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

CRANKCASE ('80 D1) KZ440D1 LTD 1980 USA CANADA / BELT DRIVE

prices are in EUR

ref

part #

description

quantity

1

130P0608
ref: 1
ASTERISK (*) MARKED

BOLT,FLANGED,6X8

€ 1.00

2

130451001
ref: 2

RECEIVER-OIL

€ 10.00

3

131691103
ref: 3

PLATE,CRANKCASE

€ 6.00

4

140015054
ref: 4

CRANKCASE SET

€ 656.50

5

14013004
ref: 5

RING-BEARING SETTING

€ 7.00

6

220B0612
ref: 6

SCREW-PAN HEAD,6X12

€ 1.00

7

290Q0606
ref: 7
ASTERISK (*) MARKED

SCREW,6X6

€ 3.00

8

920011004
ref: 8

BOLT,FLANGED,10X91

€ 6.50

9

920011005
ref: 9
ASTERISK (*) MARKED

BOLT,FLANGED,8X58

€ 5.00

9

920011005
ref: 9

BOLT,FLANGED,8X58

€ 5.00

10

92004062
ref: 10
ASTERISK (*) MARKED

STUD, 10X153

€ 13.50

11

92055048
ref: 11

RING-O,OD=18

€ 3.00

12

92066059
ref: 12
ASTERISK (*) MARKED

PLUG,PT1/8X7

€ 3.00

13

481J360
ref: 13

UNAVAILABLE IN PRICE BOOK

€ 0.00

14

92042016
ref: 14

PIN,DOWEL,6X16

€ 3.50

15

920491041
ref: 15

OIL SEAL,PUSH ROD

€ 13.00

16

92051005A
ref: 16

OIL SEAL,TB13225.5

€ 5.50

17

110091105
ref: 17

GASKET,10X14.5X1.5 (NAS)

€ 4.00

18

16115013
ref: 18

PLUG-OIL FILLER

€ 13.50

19

260111078
ref: 19

WIRE-LEAD,OIL SWITCH

€ 12.50

20

270101157
ref: 20

SWITCH,OIL PRESSURE

€ 27.50

21

920011020
ref: 21

BOLT,OIL,SWITCH

€ 8.00

22

92055049
ref: 22

'0'RING,31MM

€ 2.50

23

92065097
ref: 23

GASKET,DRAIN PLUG BOL (NAS)

€ 1.00

24

920661174
ref: 24

PLUG,OIL DRAIN,12X15

€ 4.00
