MUFFLER
KX125-D1 KX125 1985 USA CANADA
Muffler diagram KX125-D1 KX125 1985 USA CANADA
MUFFLER KX125-D1 KX125 1985 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
18002
180021551
ref: 18002
BODY-COMP-MUFFLER
€ 332.00
18046
180461060
ref: 18046
WOOL,MUFFLER BAFFLE P
€ 29.00
49069
490691053
ref: 49069
MUFFLER-ASSY
€ 150.00
49099
490991168
ref: 49099
BAFFLE-PIPE MUFFLER
€ 49.00
92002
921501340
ref: 92002
BOLT,6X14
€ 3.00
92015
920151078
ref: 92015
NUT,6M/M
€ 1.50
92027
92027194
ref: 92027
COLLAR
€ 3.50
92075
920751123
ref: 92075
DAMPER,RUBBER
€ 3.00
92075A
920751891
ref: 92075A
DAMPER,MUFFLER
€ 21.00
92075B
920751598
ref: 92075B
DAMPER,SIDE COVER
€ 5.50
130
130G0508
ref: 130
BOLT-FLANGED
€ 0.50
132
132G0625
ref: 132
BOLT-FLANGED-SMALL
€ 3.00
670
670E3045
ref: 670
O RING,45MM
€ 11.50
