BRAKE PEDAL

KL650C5 KLR650 1999 UNITED KINGDOM FR NL FG IT SP ST

Brake pedal diagram KL650C5 KLR650 1999 UNITED KINGDOM FR NL FG IT SP ST

BRAKE PEDAL KL650C5 KLR650 1999 UNITED KINGDOM FR NL FG IT SP ST

BRAKE PEDAL KL650C5 KLR650 1999 UNITED KINGDOM FR NL FG IT SP ST

prices are in EUR

ref

part #

description

quantity

550

550D2525
ref: 550

PIN-COTTER,2.5X25

€ 1.00

670

670B2014
ref: 670

O RING,14MM

€ 1.00

43077A

430771082
ref: 43077A

LEVER-ASSY-BRAKE,PEDA

€ 73.00

92144

921441853
ref: 92144

SPRING,BRAKE PEDAL RE

€ 4.00

92200

922001171
ref: 92200

WASHER,14.5X24X1.6

€ 2.50
