HANDLEBAR (S1-A)
KH250A5 1976 CANADA
Handlebar (s1-a) diagram KH250A5 1976 CANADA
HANDLEBAR (S1-A) KH250A5 1976 CANADA
×
prices are in EUR
ref
part #
description
quantity
1
46003030
ref: 1
HANDLE
€ 136.00
2
920011405
ref: 2
BOLT,8X38
€ 10.00
3
461F0800
ref: 3
WASHER-SPRING,8MM
€ 0.50
4
46012008
ref: 4
HOLDER-HANDLE,UPP
€ 23.00
5
46012010
ref: 5
HOLDER-HANDLE,LWR
€ 20.00
6
92075039
ref: 6
DAMPER RUBBER-HANDLE
€ 3.00
7
46016003
ref: 7
PLATE,HANDLE HOLDER
€ 3.50
8
461F1000
ref: 8
WASHER-SPRING,10MM
€ 0.50
9
314B1000
ref: 9
NUT,10MM
€ 0.50
10
554A0800
ref: 10
PIN-SNAP,8MM
€ 1.00
11
56002024
ref: 11
MIRROR-ASSY,RH
€ 60.00
12
56003016
ref: 12
REAR VIEW MIRROR,L.H
€ 54.00
13
56006001
ref: 13
PLATE,MIRROR
€ 8.50
14
46018024
ref: 14
CASE ASSY,R.H
€ 101.50
15
46019023
ref: 15
GRIP ASSY-THROTTLE
€ 13.50
16
46096007
ref: 16
LEVER-STARTER
€ 7.50
17
46114003
ref: 17
WASHER,WAVE
€ 3.00
18
220B0522
ref: 18
SCREW-PAN-CROS
€ 0.50
19
46021018
ref: 19
LEVER ASSY,FRNT BRAKE
€ 25.50
20
46058004
ref: 20
LEVER-GRIP,FRONT BRAK
€ 24.00
21
46060008
ref: 21
HOLDER,FR BRAKE LEVER
€ 23.00
22
92007020
ref: 22
BOLT-HEX HEAD,5X20
€ 2.50
23
46059011
ref: 23
COLLAR,LEVER
€ 3.50
24
110N0625
ref: 24
BOLT-HEX HEAD,6X25
€ 3.50
25
410B0600
ref: 25
WASHER-PLAIN-SMALL,6M
€ 0.50
26
464H0500
ref: 26
WASHER-LOCK,5MM
€ 0.50
27
312B0500
ref: 27
NUT-HEX,5MM
€ 0.50
28
46056005
ref: 28
NUT-LOCK
€ 6.00
29
46055003
ref: 29
SCREW-CABLE ADJUST
€ 11.50
30
46091005
ref: 30
CASE ASSY-L.H
€ 59.50
31
46044008
ref: 31
KNOB-L.H SWITCH,B
€ 3.00
32
221B0308A
ref: 32
SCREW-CNTSNK HD,3X8
€ 2.50
33
46044011
ref: 33
KNOB-L.H SWITCH
€ 6.00
34
46044007
ref: 34
KNOB-SWITCH
€ 8.00
35
270101009
ref: 35
SWITCH ASSY,HORN BUTN
€ 5.50
36
270101009
ref: 36
SWITCH ASSY,HORN BUTN
€ 5.50
37
270101009
ref: 37
SWITCH ASSY,HORN BUTN
€ 5.50
37
270101009
ref: 37
INCL. REF. #'S 35-37
SWITCH ASSY,HORN BUTN
€ 5.50
38
46075017
ref: 38
GRIP,LH
€ 15.50
39
46076026
ref: 39
LEVER ASSY-CLUTCH
€ 35.00
40
46092015
ref: 40
LEVER-GRIP,CLUTCH
€ 11.50
41
46094010
ref: 41
HOLDER,CLUTCH LEVER
€ 31.50
42
46055006
ref: 42
SCREW-CABLE ADJUST
€ 15.50
