SWING ARM/SHOCK ABSORBERS ('74-'
G4TRB 1972 USA CANADA
Swing arm/shock absorbers ('74-' diagram G4TRB 1972 USA CANADA
SWING ARM/SHOCK ABSORBERS ('74-' G4TRB 1972 USA CANADA
×
prices are in EUR
ref
part #
description
quantity
1
33001060
ref: 1
SWING ARM
€ 233.50
2
33035005
ref: 2
CAP,SWING ARM
€ 5.50
3
33032029
ref: 3
G4TR-D
SHAFT-SWING ARM
€ 18.50
3
33032029
ref: 3
G4TR-E KV100-A7
SHAFT-SWING ARM
€ 18.50
4
671B2530
ref: 4
O RING,30MM
€ 3.00
5
33034016
ref: 5
SLEEVE,12.1X22X39
€ 14.50
6
33033009
ref: 6
BUSHING,SWING ARM
€ 57.00
7
33036002
ref: 7
COLLAR,SWING ARM
€ 8.00
8
461F1200
ref: 8
G4TR-D
WASHER-SPRING,12MM
€ 0.50
8-1
410B1200
ref: 8-1
G4TR-E, KV100-A7
WASHER-PLAIN-SMALL,12
€ 0.50
9
315B1200
ref: 9
G4TR-D
NUT,12MM
€ 0.50
9
92019009
ref: 9
G4TR-E, KV100-A7
NUT,LOCK,12MM
€ 5.00
10
33040039
ref: 10
CHAIN ADJUSTER,RH
€ 17.50
11
33040040
ref: 11
CHAIN ADJUSTER,LH
€ 17.50
12
410B0800
ref: 12
WASHER-PLAIN-SMALL,8M
€ 0.50
13
461F0800
ref: 13
G4TR-D
WASHER-SPRING,8MM
€ 0.50
14
312B0800
ref: 14
G4TR-D
NUT,8MM
€ 0.50
14
312B0800
ref: 14
G4TR-E, KV100-A7
NUT,8MM
€ 0.50
15
55020013
ref: 15
CHAIN GUARD
€ 26.50
16
115G0820
ref: 16
BOLT,8X20
€ 2.00
17
461F0800
ref: 17
WASHER-SPRING,8MM
€ 0.50
18
45014073
ref: 18
SHOCK ABSORBER,REAR
€ 138.00
19
920751020
ref: 19
DAMPER,SHOCKABSORBER
€ 3.00
20
45016003
ref: 20
COLLAR,SHOCKABSORBER
€ 12.50
21
43007018
ref: 21
TORQUE LINK,REAR BRK
€ 8.50
22
92003017
ref: 22
BOLT-TRQ LINK 10X25
€ 3.50
23
461F1000
ref: 23
WASHER-SPRING,10MM
€ 0.50
24
314B1000
ref: 24
NUT,10MM
€ 0.50
25
92003003
ref: 25
BOLT-HEX HEAD,10X32
€ 4.00
26
550D2015
ref: 26
PIN-COTTER,2.0X15
€ 1.00
27
113N1035
ref: 27
BOLT-HEX HEAD,10X35
€ 6.00
28
92020003
ref: 28
NUT-SHOCK ABSORBER
€ 4.00
29
92022044
ref: 29
WASHER,10.5X26X2.3
€ 2.50
