FRAME

ZX750J1 ZXR750 1991 EUROPE UK FR AR FG GR IT NR SD SP ST

Frame diagram ZX750J1 ZXR750 1991 EUROPE UK FR AR FG GR IT NR SD SP ST

FRAME ZX750J1 ZXR750 1991 EUROPE UK FR AR FG GR IT NR SD SP ST
FRAME ZX750J1 ZXR750 1991 EUROPE UK FR AR FG GR IT NR SD SP ST
FRAME ZX750J1 ZXR750 1991 EUROPE UK FR AR FG GR IT NR SD SP ST
prices are in EUR
ref
part #
description
quantity
32160
321601179KF
ref: 32160
AREUFGFRGRITNRSDSTUK
FRAME-COMP,FR,SILVER
€ 1,253.00
32160A
32160117910
ref: 32160A
AREUFGFRGRITNRSDSTUK
FRAME-COMP,FR,BLACK
€ 1,253.00
32160B
321601182KF
ref: 32160B
FRAME-COMP,AL,RR,SILV
€ 451.00
32160C
32160118210
ref: 32160C
FRAME-COMP,AL,RR,BLAC
€ 451.00
32160D
321601208KF
ref: 32160D
SP
FRAME-COMP,FR,SILVER
€ 1,253.00
32160E
32160120810
ref: 32160E
SP
FRAME-COMP,FR,BLACK
€ 1,253.00
92015
920151791
ref: 92015
NUT,POP,6MM
920151791
€ 3.00
92015A
920151792
ref: 92015A
NUT,POP,6MM,L=16.5
920151792
€ 3.00
92015B
920151793
ref: 92015B
NUT,POP,8MM
920151793
€ 3.00
92015C
920151847
ref: 92015C
NUT,CAP,25MM
920151847
€ 16.00
92015D
920151848
ref: 92015D
NUT,STEERING STEM,35M
920151848
€ 32.50
92049
920491382
ref: 92049
SEAL-OIL,XMH 43 75 6.
920491382
€ 16.00
92049A
920491383
ref: 92049A
SEAL-OIL,XMHE 43 55 4
920491383
€ 13.00
92055
920551452
ref: 92055
RING-O,34.5X2.0
920551452
€ 3.00
92116
921161072
ref: 92116
BEARING-ROLLER,32907J
921161072
€ 76.50
92116A
921161074
ref: 92116A
BEARING-ROLLER,32907J
921161074
€ 76.50
92200
922001083
ref: 92200
WASHER,CLAW,25.5X40X2
922001083
€ 4.50
92200A
922001084
ref: 92200A
WASHER,25.5X42X2.3
922001084
€ 3.50
