STARTER MOTOR

ref

part #

description

quantity

120

120S0510
ref: 120

BOLT-SOCKET

€ 0.50

150

150R0510
ref: 150

BOLT-WS,5X10

€ 3.50

461

461K0500
ref: 461

WASHER-SPRING,5MM,BLA

€ 0.50

555

555A0316
ref: 555

PIN-SPRING,3X16

€ 1.00

11054

110541175
ref: 11054

BRACKET

€ 137.50

13107

131070162
ref: 13107

SHAFT,STARTER SIDE

€ 10.00

13107A

131070168
ref: 13107A

SHAFT,ONEWAY CLUTCH S

€ 48.50

13183

131831460
ref: 13183

PLATE

€ 9.00

13194

131943705
ref: 13194

CLUTCH-ONEWAY

€ 88.00

13280

132800109
ref: 13280

HOLDER,SWITCH

€ 9.00

16085

160850101
ref: 16085

GEAR,29T

€ 103.00

21163

211630041
ref: 21163

STARTER-ELECTRIC

€ 647.00

26006

260061006
ref: 26006

FUSE,30A-G

€ 3.00

26011

260110118
ref: 26011

WIRE-LEAD

€ 35.50

27010

270100030
ref: 27010

SWITCH,MAGNETIC

€ 119.00

32099

320990026
ref: 32099

CASE,STARTER CLUTCH

€ 87.00

59051

590510068
ref: 59051

GEAR-SPUR,ONEWAY CLUT

€ 65.00

59051A

590510069
ref: 59051A

GEAR-SPUR,STARTER SID

€ 64.00

92033

920333731
ref: 92033

RING-SNAP

€ 4.00

92046

920460004
ref: 92046

BEARING-NEEDLE,RS2630

€ 24.50

92055

920550013
ref: 92055

RING-O,STARTER

€ 8.50

92055A

920550126
ref: 92055A

RING-O

€ 4.00

92055B

920551455
ref: 92055B

RING-O

€ 9.50

92071

920710031
ref: 92071

GROMMET

€ 8.50

92144

921441423
ref: 92144

SPRING,BRUSH

€ 3.00

92151

921511874
ref: 92151

BOLT,6X35

€ 2.00

92153

921530405
ref: 92153

BOLT

€ 15.50

92153A

921531521
ref: 92153A

BOLT,TORX,10X38

€ 6.50

92200

922000238
ref: 92200

WASHER,10.5X37X1.6

€ 2.50

92200A

922001019
ref: 92200A

WASHER

€ 5.00
