CRANKCASE BOLT PATTERN

ZR750C4 ZEPHYR 750 1994 EUROPE UK FR AR FG GR NR SP ST

Crankcase bolt pattern diagram ZR750C4 ZEPHYR 750 1994 EUROPE UK FR AR FG GR NR SP ST

CRANKCASE BOLT PATTERN ZR750C4 ZEPHYR 750 1994 EUROPE UK FR AR FG GR NR SP ST

CRANKCASE BOLT PATTERN ZR750C4 ZEPHYR 750 1994 EUROPE UK FR AR FG GR NR SP ST

prices are in EUR

ref

part #

description

quantity

130

130Y06100
ref: 130

BOLT-FLANGED

€ 4.50

130A

130Y06105
ref: 130A

BOLT-FLANGED

€ 3.00

130B

130Y06115
ref: 130B

BOLT-FLANGED

€ 3.50

130C

130Y0640
ref: 130C

BOLT-FLANGED

€ 3.00

130D

130Y0650
ref: 130D

BOLT-FLANGED

€ 3.00

92002

920021077
ref: 92002

BOLT,8X95

€ 7.50

92042

92042016
ref: 92042

PIN,DOWEL,6X16

€ 3.50

92043

920431263
ref: 92043

PIN,DOWEL,6.2X8X14

€ 0.50
