GEAR CHANGE MECHANISM

VN900C7F VULCAN 900 CUSTOM 2007 USA CALIFORNIA CANADA

Gear change mechanism diagram VN900C7F VULCAN 900 CUSTOM 2007 USA CALIFORNIA CANADA

GEAR CHANGE MECHANISM VN900C7F VULCAN 900 CUSTOM 2007 USA CALIFORNIA CANADA
GEAR CHANGE MECHANISM VN900C7F VULCAN 900 CUSTOM 2007 USA CALIFORNIA CANADA
GEAR CHANGE MECHANISM VN900C7F VULCAN 900 CUSTOM 2007 USA CALIFORNIA CANADA
prices are in EUR
ref
part #
description
quantity
130
130W0620
ref: 130
BOLT-FLANGED
€ 2.00
480
480J1300
ref: 480
CIRCLIP-TYPE-C,13MM
480J1300
€ 2.50
13063
13063002
ref: 13063
RUBBER-KICK PEDAL
13063002
€ 3.00
13161
131610046
ref: 13161
LEVER-COMP-CHANGE SHA
131610046
€ 64.50
13165
131651151
ref: 13165
PAWL,CHANGE LEVER
131651151
€ 9.50
13236
132360132
ref: 13236
LEVER-COMP
€ 41.50
13236A
132360133
ref: 13236A
LEVER-COMP
132360133
€ 112.00
13236B
132361126
ref: 13236B
LEVER-COMP,POSITION
132361126
€ 9.00
39110
391101100
ref: 39110
ROD-ASSY-TIE
391101100
€ 12.50
92001
920011715
ref: 92001
BOLT
920011715
€ 7.00
92015
920151443
ref: 92015
NUT
920151443
€ 2.50
92015A
920151444
ref: 92015A
NUT
920151444
€ 3.00
92015B
920151649
ref: 92015B
NUT,10MM
920151649
€ 3.50
92022
920221224
ref: 92022
WASHER,13.2X20X0.5
920221224
€ 2.50
92049
920490093
ref: 92049
SEAL-OIL
920490093
€ 4.00
92144
921441029
ref: 92144
SPRING
921441029
€ 5.00
92144A
921441074
ref: 92144A
SPRING,CHANGE PEDAL R
921441074
€ 6.50
92145
921450462
ref: 92145
SPRING,RETURN
921450462
€ 5.50
92150
921501869
ref: 92150
BOLT,RETURN SPRING
€ 7.00
92151
921511785
ref: 92151
BOLT,FLANGED,10X54
€ 2.50
92152
921520531
ref: 92152
COLLAR,10.5X17X30.5
€ 12.50
92200
922000352
ref: 92200
WASHER,11X26X2.6
922000352
€ 2.00
