SECONDARY SHAFT ('80 H1)

KZ750H1 1980 USA CANADA / LTD

Secondary shaft ('80 h1) diagram KZ750H1 1980 USA CANADA / LTD

prices are in EUR

ref

part #

description

quantity

920751227
ref: 1

DAMPER

€ 4.50

13122007
ref: 2

CHAIN,63-139X52L(TUBA

€ 325.50

131271019
ref: 3

SHAFT,SECONDARY

€ 244.00

13252001
ref: 4

COUPLING,OUTER,SECOND

€ 226.50

13253001
ref: 5

COUPLING,INNER,SECOND

€ 180.50

480J2800
ref: 6

CIRCLIP-TYPE-C,28MM

€ 3.50

601B6205
ref: 7

BEARING-BALL,#6205C3

€ 14.00

601B6305
ref: 8

BEARING-BALL,#6305C3

€ 30.00

92015019
ref: 9

NUT,18MM

€ 4.00

920281037
ref: 10

BUSHING,20X25X16.6

€ 16.00
