FUEL TANK

ref

part #

description

quantity

1

510481001
ref: 1

CAP-ASSY-TANK,FUEL

€ 75.50

2

110091053
ref: 2

GASKET,TANK CAP (NAS)

€ 3.50

3

560141038
ref: 3
KZ650-D2

EMBLEM,FUEL TANK

€ 36.50

4

510011006A5
ref: 4
KZ650-D1/D1A

FUEL TANK,CANDY PERSIMMON RED

€ 598.50

5

560141009
ref: 5
KZ650-D1/D1A

FUEL TANK EMBLEM,LH

€ 24.50

6

221C0306
ref: 6

SCREW-CSR-CROS

€ 0.50

7

560141010
ref: 7
KZ650-D1/D1A

FUEL TANK EMBLEM,RH

€ 35.00

8

92022183
ref: 8

WASHER,6.2X11X1.5

€ 2.50

9

920011091
ref: 9

BOLT,6X20,FUEL TAP

€ 2.50

10

510231023
ref: 10

TAP ASSY,FUEL

€ 115.00

11

220B0308
ref: 11

SCREW-PAN-CROS

€ 0.50

12

110091194
ref: 12

GASKET,TAP VALVE (NAS)

€ 6.50

13

51039010
ref: 13

RING,TAP FLANGED

€ 4.50

14

110091045
ref: 14

GASKET,DRAIN BOLT

€ 1.00

15

920011089
ref: 15

BOLT,DRAIN

€ 8.00

16

430281004
ref: 16
NO LONGER AVAILABLE

DIAPHRAGM ASSY,TAP

€ 4.50

16

430281015
ref: 16
USE FOR 51023-1023

DIAPHRAGM,TAP

€ 14.50

17

920811055
ref: 17

SPRING,TAP

€ 2.50

17

920811171
ref: 17
USE FOR 51023-1023

SPRING,TAP

€ 2.50

18

161461005
ref: 18

COVER-ASSY,TAP DIAPHR

€ 14.00

19

221B0412A
ref: 19

SCREW,CNTSNK HD,4X12

€ 2.00

20

270101096
ref: 20

SWITCH,FUEL LEVEL

€ 109.50

21

920221023
ref: 21

WASHER,5.2X10X1.5

€ 2.50

22

220B0514
ref: 22

ACREW-PAN HEAD,5X14

€ 2.50

23

430581004
ref: 23

O RING,FUEL LEVL SW

€ 5.50

24

920551027
ref: 24
USE FOR 51023-1013/1

RING-O,TAP LEVER

€ 3.50

25

5100110068E
ref: 25
KZ650-D2

TANK,FUEL,M.BLUE

€ 612.00

25

510015029A5
ref: 25
KZ650-D2

FUEL TANK,CANDY PERSIMMON RED

€ 488.00

26

670B1504
ref: 26
USE FOR 51023-1023

O RING,4MM

€ 2.50
