GENERATOR/REGULATOR ('80 A1)

KZ440A4 LTD 1983 USA CANADA

Generator/regulator ('80 a1) diagram KZ440A4 LTD 1983 USA CANADA

GENERATOR/REGULATOR ('80 A1) KZ440A4 LTD 1983 USA CANADA

GENERATOR/REGULATOR ('80 A1) KZ440A4 LTD 1983 USA CANADA

prices are in EUR

ref

part #

description

quantity

1

120P0628
ref: 1

BOLT,ALLEN,6X28

€ 3.00

2

131691008
ref: 2

PLATE,LEAD CLAMP

€ 2.00

3

210031009
ref: 3

STATOR ASSY,GENERATER

€ 332.50

4

210501004
ref: 4

FLYWHEEL,GENERATOR

€ 560.50

5

210661014
ref: 5

REGULATOR-VOLTAGE

€ 170.50

6

21126008
ref: 6

CLAMP,WIRING HARNESS

€ 3.00

7

220B0610
ref: 7

SCREW-PAN HEAD,6X10

€ 2.00

8

920021303
ref: 8

BOLT,10X40

€ 9.50

9

220B0614
ref: 9

SCREW-PAN HEAD,6X14

€ 2.00
