TRANSMISSION

ref

part #

description

quantity

13127

131271126
ref: 13127

SHAFT-TRANSMISSION

€ 225.50

13128

131281042
ref: 13128

SHAFT-TRANSMISSION OU

€ 174.00

13129

131291132
ref: 13129

4TH GEAR,OUTPUT,21T

€ 112.00

13129A

131291133
ref: 13129A

TOP GEAR,OUTPUT,19T

€ 60.00

13129B

131291180
ref: 13129B

GEAR,OUTPUT LOW,32T

€ 93.50

13129C

131291407
ref: 13129C

GEAR,INPUT 2ND,22T

€ 57.00

13129D

131291408
ref: 13129D

GEAR,INPUT 3RD,22T

€ 87.50

13129E

131291409
ref: 13129E

GEAR,INPUT 4TH,22T

€ 102.50

13129F

131291410
ref: 13129F

GEAR,INPUT TOP,24T

€ 94.50

13129G

131291622
ref: 13129G

GEAR-OUTPUT 2ND,32T

€ 102.50

13129H

131291679
ref: 13129H

GEAR-OUTPUT 3RD,26T

€ 156.00

13144

13144055
ref: 13144
(OPTION)

SPROCKET-OUTPUT,13T

€ 28.50

13144A

131441006
ref: 13144A
(OPTION)

SPROCKET-OUTPUT,14T

€ 24.00

13144B

131441026
ref: 13144B

SPROCKET-OUTPUT,15T

€ 44.00

92013

42045008
ref: 92013

NUT,24MM

€ 6.50

92022

92022159
ref: 92022

WASHER-THRUST,25MM

€ 5.50

92022A

92022255
ref: 92022A

WASHER

€ 5.50

92022B

92024038
ref: 92022B

WASHER-LOCK

€ 4.00

92022C

92024065
ref: 92022C

WASHER,LOCK

€ 3.50

92027

92027247
ref: 92027

COLLAR,R.H CRANKSHAFT

€ 9.50

92033

92033026
ref: 92033

CIRCLIP

€ 6.00

92033A

92033029
ref: 92033A

CIRCLIP,18MM

€ 6.50

92033B

92033032
ref: 92033B

CIRCLIP

€ 3.00

92046

92046036
ref: 92046

BEARING,KT202614

€ 9.00

92046A

920461059
ref: 92046A

BEARING-NEEDLE,K17X23

€ 20.00

92055

92055035
ref: 92055

O RING

€ 3.00
