FOOTRESTS/STAND/BRAKE PEDAL

ref

part #

description

quantity

1

340271114
ref: 1

STEP-ASSY,FR,LH

€ 24.00

2

92022250
ref: 2

WASHER,PLAIN

€ 3.00

3

92043080
ref: 3

PIN-FOOTREST BAR FIT

€ 3.50

4

550D2516
ref: 4

PIN-COTTER,2.5X16

€ 1.50

5

34007013
ref: 5

BRACKET,L.H FOOTREST

€ 70.50

6

461F1400
ref: 6

WASHER-SPRING,14MM

€ 0.50

7

113B1432
ref: 7

BOLT-HEX HEAD,14X32

€ 6.50

8

34007014
ref: 8

BRACKET,R.H FOOTREST

€ 64.50

9

340271115
ref: 9

STEP-ASSY,FR,RH

€ 24.00

10

920011252
ref: 10

BOLT,HEX HEAD,10X35

€ 3.50

11

34025008
ref: 11

SPRING,SIDE STAND

€ 4.50

12

340241043
ref: 12

STAND,SIDE

€ 34.00

13

314B1000
ref: 13

NUT,10MM

€ 0.50

14

43001065
ref: 14

PEDAL,BRAKE

€ 28.00

15

43005032
ref: 15

SPRING,BRAKE PEDAL

€ 4.00

16

92022193
ref: 16

WASHER,6.5X20X1.6,WHI

€ 3.50

17

461F0600
ref: 17

WASHER-SPRING,6MM

€ 0.50

18

220E0610
ref: 18

SCREW-PAN HEAD,6X10

€ 2.50

19

92076027
ref: 19
KE175-B2/-B3

DAMPER,STEP,RR

€ 19.00

20

92022199
ref: 20
KE175-B2/-B3

WASHER,20X30X2.3

€ 5.00

21

920431464
ref: 21
KE175-B2/-B3

PIN

€ 5.50

22

550D2012
ref: 22
KE175-B2/-B3

PIN,COTTER,2.0X12

€ 0.50

23

34029013
ref: 23
KE175-B2/-B3

BRACKET R.FOOTREST

€ 15.50

24

461F1000
ref: 24
KE175-B2/-B3

WASHER-SPRING,10MM

€ 0.50

25

314B1000
ref: 25
KE175-B2/-B3

NUT,10MM

€ 0.50

all assemblies
