CHASSIS ELECTRICAL EQUIPMENT

ref

part #

description

quantity

1

26001123
ref: 1

MAGNETO WIRING HARNESS

€ 287.00

2

26002054
ref: 2

HEADLAMP WIRING HARNESS

€ 202.00

3

26011072
ref: 3

WIRE,RECTIFIER LEAD

€ 7.00

4

26002046
ref: 4

HARNESS,TAIL LAMP

€ 12.50

5

26011093
ref: 5

WIRE-LEAD

€ 6.00

6

26004025
ref: 6

FUSE-ASSY

€ 12.50

7

26006007
ref: 7

FUSE 15A

€ 2.50

8

26016004
ref: 8

HOLDER,SPARE FUSE

€ 7.50

9

26006007
ref: 9

FUSE 15A

€ 2.50

10

92072030
ref: 10
L=123M/M

BAND,SHORT

€ 3.00

11

92072031
ref: 11
(N/R KE175-B2/-B3)

BAND,MIDDLE

€ 3.00

12

92072032
ref: 12
L=218M/M

BAND,LONG

€ 3.00

13

92072068
ref: 13

BAND,WIRING HARNESS

€ 2.50

14

92075250
ref: 14

DAMPER RUBBER,HARNES

€ 1.50

15

26009008
ref: 15

COVER,WIRING HARNESS

€ 3.50

16

27010025
ref: 16

SWITCH,BRAKE LAMP

€ 18.50

17

27011018
ref: 17

SPRING,BRAKE LAMP SW

€ 2.00

18

K26012034
ref: 18

BATTERY,YUA,6N6-1D-2

€ 78.00

18

K26012034
ref: 18
KE175-B2/-B3

BATTERY,YUA,6N6-1D-2

€ 78.00

19

560401036
ref: 19

WARNING, BATTERY

€ 2.00

20

27003044
ref: 20

HORN

€ 113.50

21

27002013
ref: 21

RELAY-ASSY,TURN SIGNA

€ 27.00
