GEAR CHANGE MECHANISM

EX500A3 GPZ500S 1989 EUROPE UK AR

Gear change mechanism diagram EX500A3 GPZ500S 1989 EUROPE UK AR

GEAR CHANGE MECHANISM EX500A3 GPZ500S 1989 EUROPE UK AR
GEAR CHANGE MECHANISM EX500A3 GPZ500S 1989 EUROPE UK AR
GEAR CHANGE MECHANISM EX500A3 GPZ500S 1989 EUROPE UK AR
prices are in EUR
ref
part #
description
quantity
130
130S0620
ref: 130
BOLT-FLANGED,6X20,BLA
130S0620
€ 2.50
172
172G0614
ref: 172
STUD,6X14
172G0614
€ 1.00
311
311G0600
ref: 311
NUT,6M/M
311G0600
€ 0.50
311A
311J0600
ref: 311A
NUT-HEX
311J0600
€ 1.00
482
482J0200
ref: 482
CIRCLIP-TYPE-E,12MM
482J0200
€ 2.50
482A
482L7000
ref: 482A
CIRCLIP-TYPE-E
482L7000
€ 2.50
13161
131611117
ref: 13161
LEVER-COMP-CHANGE SHA
131611117
€ 56.00
13165
131651034
ref: 13165
PAWL,CHANGE LEVER
131651034
€ 7.00
13236
132361103
ref: 13236
LEVER-COMP,GEAR POSIT
132361103
€ 13.00
13236A
132361153
ref: 13236A
LEVER-COMP,CHANGE PED
132361153
€ 51.50
13236B
132361154
ref: 13236B
LEVER-COMP,CHANGE LIN
132361154
€ 55.00
39110
391101077
ref: 39110
ROD-ASSY-TIE
391101077
€ 9.50
92001
920011455
ref: 92001
BOLT
920011455
€ 3.00
92002
920021926
ref: 92002
BOLT,CHANGE PEDAL
920021926
€ 10.50
92015
920151178
ref: 92015
NUT
920151178
€ 2.50
92022
920221537
ref: 92022
WASHER,12.5X21X1.2,BL
920221537
€ 3.50
92022A
920221561
ref: 92022A
WASHER,8.5X20X1.6
920221561
€ 2.50
92026
92026094
ref: 92026
WASHER,THRUST
92026094
€ 6.50
92026A
920261217
ref: 92026A
SPACER
920261217
€ 3.50
92027
920271440
ref: 92027
COLLAR,13X18.3X21.5
920271440
€ 3.50
92075
13157007
ref: 92075
RUBBER, SHIFT PEDAL
13157007
€ 3.50
92081
920811387
ref: 92081
SPRING,RETURN
920811387
€ 6.50
92081A
920811785
ref: 92081A
SPRING,CHANGE LEVER
920811785
€ 6.00
92144
921441180
ref: 92144
SPRING,POSITION LEVER
921441180
€ 6.00
