CHASSIS ELECTRICAL EQUIPMENT (H2

H2C MACH IV 1975 CANADA

Chassis electrical equipment (h2 diagram H2C MACH IV 1975 CANADA

CHASSIS ELECTRICAL EQUIPMENT (H2 H2C MACH IV 1975 CANADA
CHASSIS ELECTRICAL EQUIPMENT (H2 H2C MACH IV 1975 CANADA
CHASSIS ELECTRICAL EQUIPMENT (H2 H2C MACH IV 1975 CANADA
prices are in EUR
ref
part #
description
quantity
1
26001112
ref: 1
WIRING HARNESS,MAIN
€ 154.50
2
26002043
ref: 2
WIRING HARNESS,REAR
26002043
€ 31.50
3
26010037
ref: 3
WIRE,BATTERY LEAD
€ 8.00
4
26011082
ref: 4
WIRE-LEAD,GROUND
€ 3.50
5
26011084
ref: 5
H2-B
WIRE,GROUND LEAD
€ 10.50
6
26004019
ref: 6
FUSE ASSY
€ 4.50
7
26006005
ref: 7
FUSE 20A
26006005
€ 3.50
8
26016003
ref: 8
HOLDER,SPARE FUSE
26016003
€ 8.50
9
26006005
ref: 9
FUSE 20A
26006005
€ 3.50
10
K26012022
ref: 10
12N5.5-4A
BATTERY,YUA,12N5.5-4A
€ 115.50
11
92072030
ref: 11
BAND,SHORT
92072030
€ 3.00
12
92072031
ref: 12
BAND,MIDDLE
92072031
€ 3.00
13
92072056
ref: 13
BAND,RUBBER
92072056
€ 3.00
14
27010020
ref: 14
H2-B
SWITCH,BRAKE LAMP
27010020
€ 29.50
14
27010023
ref: 14
H2-C
SWITCH,BRAKE LIGHT
€ 26.00
15
27011013
ref: 15
SPRING-BRAKE LAMP SW
27011013
€ 9.50
16
27002011
ref: 16
RELAY-ASSY,TURN SIGNA
27002011
€ 69.50
17
27003042
ref: 17
HOON
€ 110.50
18
115G0816
ref: 18
BOLT-HEX,HEAD 8X16
115G0816
€ 0.50
19
461F0800
ref: 19
WASHER-SPRING,8MM
461F0800
€ 0.50
20
92072032
ref: 20
H2-C
BAND,LONG
92072032
€ 3.00
21
27037001
ref: 21
H2-C
NUT,BRAKE LAMP SWICH
€ 18.50
22
28019001
ref: 22
SWITCH,OUTAGE INDICTR
28019001
€ 46.00
